Resilient and Pioneering | Spirit of Your Business
Your business should be empowered to stop at nothing while navigating your journey with the MSI Business & Productivity Series products.
Small But Powerful
Compact and versatile, this 0.66-liter mini PC is ideal for small workspaces, home entertainment sets, and a variety of industries.
Efficient and Stable: Cubi N, the Energy-Saving Solution.
With built-in UHD Graphics, 4 cores, and 4 threads, Cubi N save more power and energy source while satisfying your usage requirements with only 6W TDP.
Support up to Three Displays in 4K Resolution
With HDMI™, DP, and Type-C port, Cubi N allows you to extend to three monitors to preview your E-commerce content & data at home or in the office, enhancing your efficiency.
Limitless Wireless Connection | MSI Cloud Center + Wifi
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS devices faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.
HW TPM 2.0 Support
dTPM 2.0 (Trusted Platform Module) technology is designed to provide hardware-based, security-related functions.You can store your sensitive data & passwords by encryption keys for advanced security.
USB 3.2 Type-C Connect All You Need
Type C offers a universal solution for connecting devices with high-speed data transfer, display capabilities, and charging functionality. It's a game-changer for device compatibility and connectivity, enabling easy data transfer and device powering.
Key Features
- Serial ATA interface provides quick data transfer and greater throughput
- DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Connect USB-enabled devices via 5 USB ports
Dimensions
| Height | 6.2 inches |
|---|---|
| Width | 8.02 inches |
| Length | 10 inches |
| Weight | 4 pounds |
| Product Type | Barebone System |
| Maximum Memory Supported | 64 GB |
| Limited Warranty | 1 Year |
| Chipset | Intel |
| Processor Type | N-series |
| Controller Type | Serial ATA |
| Processor Socket | Socket BGA-1264 |
| Brand Name | MSI |
| Operating System Supported | Windows 10 Home |
| Operating System Supported | Windows 10 Pro |
| Memory Technology | DDR4 SDRAM |
| Processor Core | Quad-core (4 Core) |
| Graphics Controller Model | UHD Graphics |
| Wireless LAN | Yes |
| Number of SATA Interfaces | 1 |
| Graphics Memory Accessibility | Shared |
| Wireless LAN Standard | IEEE 802.11ac |
| Number of Processors Supported | 1 |
| Ethernet Technology | Gigabit Ethernet |
| Maximum Power Supply Wattage | 65 W |
| DisplayPort | Yes |
| Product Family | Cubi N ADL |
| Total Number of USB Ports | 5 |
| Product Color | Black |
| Color Family | Black |
| Total Number of Memory Slots | 2 |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Chipset Manufacturer | Intel |
| Controller Type | Serial ATA |
| Product Type | Barebone System |
| Manufacturer Part Number | CUBINADL019B |
| Manufacturer Website Address | http://www.msi.com |
| Manufacturer | MSI |
| Product Model | Cubi N ADL-019BUS |
| Product Name | Cubi N ADL-019BUS Barebone System |
| Product Line | Cubi N ADL |
| Brand Name | MSI |
| Number of Total Expansion Bays | 1 |
| Number of M.2 Interfaces | 1 |
| Number of SATA Interfaces | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Total Number of USB Ports | 5 |
| HDMI (Rear) | Yes |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Number of USB 3.2 Gen 2 Type-C Ports | 1 |
| Maximum Memory Supported | 64 GB |
| Memory Technology | DDR4 SDRAM |
| Total Number of Memory Slots | 2 |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11ac |
| Weight (Approximate) | 1 lb |
| Height | 2.1" |
| Width | 4.9" |
| Depth | 4.9" |
| Product Color | Black |
| Color Family | Black |
| Maximum Power Supply Wattage | 65 W |
| Processor Type | N-series |
| Processor Socket | Socket BGA-1264 |
| Processor Model | N200 |
| Processor Core | Quad-core (4 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Type | N-series |
| Processor Socket | Socket BGA-1264 |
| Processor Model | N200 |
| Processor Core | Quad-core (4 Core) |
| Chipset Manufacturer | Intel |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Limited Warranty | 1 Year |
