The Perle C-10GT-XFPH is a high-performance media converter module designed for transparently extending 10 Gigabit Ethernet (10GbE) connections over various fiber optic types. It is specifically engineered to operate within the Perle MCR1900 Media Converter Chassis, providing a robust and scalable solution for network infrastructure. This module facilitates the conversion between 10GBASE-T copper Ethernet and 10GbE fiber optic links. It features a standard RJ45 port for the 10GBASE-T connection and an adaptable slot that accepts either SFP+ or XFP fiber transceivers. This flexibility allows for seamless integration with both multimode and single-mode fiber networks, including support for CWDM and DWDM wavelengths for extended reach and increased bandwidth. For copper-to-copper connectivity, the module can also accommodate SFP+ Direct Attach Cables (DAC), also known as twinax cables, or XFP 10GBASE-CX4 transceivers, offering further versatility for short-reach datacenter applications.
Dimensions
| Height | 2.8 inches |
|---|---|
| Width | 6.7 inches |
| Length | 10.2 inches |
| Weight | 0.7 pounds |
| Product Type | Transceiver/Media Converter |
| Maximum Distance Supported | 0.10 km |
| Form Factor | Internal |
| Network Technology | 10GBase-T |
| Brand Name | Perle |
| Expansion Slot Type | XFP |
| Ethernet Technology | 10 Gigabit Ethernet |
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Media Type Supported | Twisted Pair |
| Total Number of Ports | 1 |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | 05061560 |
| Manufacturer Website Address | http://www.perle.com |
| Manufacturer | Perle Systems, Inc |
| Product Model | C-10GT-XFPH |
| Product Name | 10 Gigabit Ethernet Media Converter Module |
| Brand Name | Perle |
| Expansion Slot Type | XFP |
| Number of XFP Slots | 1 |
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Parallel Port | No |
| Management Port | No |
| Digital Audio | No |
| Digital Audio/Video | No |
| Total Number of Ports | 1 |
| Maximum Distance Supported | 0.10 km |
| Media Type Supported | Twisted Pair |
| Compatibility | Perle MCR1900 Media Converter Chassis |
| Certifications & Standards |
|
| Country of Origin | Canada |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Network Technology | 10GBase-T |
