The ST1000SPEX2L Low-Profile PCIe Gigabit Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.
Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter offers effective network performance.
The card comes pre-configured with a low-profile/half-height installation bracket and includes a standard profile bracket for installation in a wide range of computer/server chassis, regardless of form factor.
Backed by a 2-year StarTech.com warranty and free lifetime technical support.
More from the Manufacturer
More from the Manufacturer
Key Features
- Enjoy superfast data transfer of up to 250 MB/s with PCI Express card, between the network card and motherboards
- Enjoy the super fast Gigabit Ethernet connection by inserting this Gigabit Ethernet card into your computer
- With the 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over the twisted pair cable
- Supports cost-efficient twisted pair cables for speedy data transfer up to 100 meters
- Add your computer to your home or office network with this single port gigabit ethernet card conveniently
Dimensions
| Height | 1.25 inches |
|---|---|
| Width | 5.75 inches |
| Length | 7 inches |
| Weight | 0.25 pounds |
| Host Interface | PCI Express |
| Product Type | Gigabit Ethernet Card |
| Device Supported | PC |
| Form Factor | Plug-in Card |
| Network Technology | 10/100/1000Base-T |
| Brand Name | StarTech.com |
| Country of Origin | China |
| Maximum Data Transfer Rate | 8 Gbit/s |
| Number of Network (RJ-45) Ports | 1 |
| Total Number of Ports | 1 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Product Type | Gigabit Ethernet Card |
| Manufacturer Part Number | ST1000SPEX2L |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | 1 Port PCI Express PCIe Gigabit NIC Server Adapter Network Card - Low Profile |
| Brand Name | StarTech.com |
| Host Interface | PCI Express |
| USB | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Serial Port | No |
| Total Number of Ports | 1 |
| Ethernet AUI | No |
| XJACK | No |
| PoE (RJ-45) Port | No |
| Media Type Supported | Twisted Pair |
| Package Contents |
|
| System Requirements |
|
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Network Technology | 10/100/1000Base-T |
| Thickness | 700 mil |
| Weight (Approximate) | 1 oz |
| Form Factor | Plug-in Card |
| Length | 2.8" |
| Height | 1.9" |
| Width | 0.7" |
| Card Length | Half-length |
| Card Height | Low-profile |
| Chipset Manufacturer | Realtek |
| Chipset Model | RTL8111 |
