CM8100 Console Server
The CM8100 is Opengear's newest console manager for data centers and enterprise networks, available in 1GbE and 10GbE models. The CM8100 Console Manager provides up to 96 serial ports, enterprise-grade security using TPM 2.0 module, and independent monitoring using dual power supplies.
Connect 16, 32, 48 or 96 serial console ports with simple straight-through cabling to Cisco®-style serial consoles reliably regardless of the state of your production network.
Host containerized applications to run across any platform or automation tools providing more agility and efficiency. Manage at scale through Opengear's Lighthouse Software.
Designed and purpose-built energy efficient without compromising performance, the CM8100 requires less power and cooling for a lower total cost of ownership and high reliability.
- 16, 32, 48, and 96 port serial console server with Smart Out-of-Band™
- REST API support for automation tools, Docker, and Python scripting
- Hardware-based TPM 2.0 provides data encryption and secure boot
- Dual power supplies with independent monitoring
- 10Gb SFP+ uplinks connect directly to high-speed networks
- Port auto-discovery simplifies configuration of serial settings and port labels
- Eliminates the need for serial adapters with selectable software serial ports
Key Features
- 16, 32. or 96* port serial console server with Smart OOB™
- Ideal replacement for legacy terminal servers
- Enables Data Center automation with Python and Docker support
- Embedded physical security using TPM 2.0 module
- Dual power supplies with independent monitoring
Dimensions
| Height | 3.5 inches |
|---|---|
| Width | 16.5 inches |
| Length | 19.6 inches |
| Weight | 9.67 pounds |
| Product Type | Device Server |
| Form Factor | Rack-mountable |
| Brand Name | Opengear |
| Network Standard | 10GBase-X |
| Network Standard | 1000Base-T |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| Number of USB Ports | 2 |
| Serial Port | Yes |
| Product Family | CM8100-10G |
| Media Type Supported | Twisted Pair |
| Media Type Supported | Optical Fiber |
| Number of Serial Ports | 48 |
| Device Type | Console Server |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | Device Server |
| Manufacturer Part Number | CM814810GUS |
| Manufacturer Website Address | http://www.opengear.com |
| Manufacturer | Opengear |
| Product Model | CM8148-10G |
| Product Name | CM8148-10G Device Server |
| Product Series | CM8100-10G |
| Brand Name | Opengear |
| Total Number of Expansion Slots | 2 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Number of USB Ports | 2 |
| Serial Port | Yes |
| Number of Serial Ports | 48 |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Maximum Memory Supported | 32 GB |
| Standard Memory | 1.95 GB |
| Memory Technology | DDR4 SDRAM |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Network Standard | 10GBase-X |
| Network Standard | 1000Base-T |
| Ethernet Technology | 10 Gigabit Ethernet |
| Weight (Approximate) | 8 lb |
| Height | 1.8" |
| Width | 17.3" |
| Depth | 10.5" |
| Processor Speed | 1.60 MHz |
| Device Type | Console Server |
