The HGST 4U60 Storage Enclosure is a high-density, scalable, and costeffective design, up to 60 Ultrastar® 3.5-inch drive modules (in multiples of 12) in a 4U enclosure. It offers 2x2x4-lane SAS 12Gb/s performance, high availability (HA), and hot-swappable components. The design is targeted towards data centers that need a dense solution with HA capabilities, while maintaining a low power profile.
Key Features
- Compact in size but massive in performance. Provides sufficient external data storage, with ultra-fast data transfer speeds and configurable modes.
- Ensures convenient and safe installation with rack mounting facility
- Featuring Non-RAID Mode - Data reliability, fault tolerance, and enhanced performance through jbod
Dimensions
| Host Interface | Mini-SAS HD |
| Product Type | Drive Enclosure |
| Form Factor | Rack-mountable |
| Brand Name | HGST |
| Number of Total Expansion Bays | 60 |
| Number of 3.5" Bays | 60 |
| Total Hard Drive Capacity Installed | 360 TB |
| Drive Interface | 12Gb/s SAS |
| Non-RAID Mode | JBOD |
| Product Type | Drive Enclosure |
| Manufacturer Part Number | HS00165 |
| Manufacturer Website Address | http://www.wdc.com |
| Manufacturer | Western Digital Corporation |
| Product Model | 4U60 |
| Product Name | 4U60 Storage Enclosure |
| Brand Name | HGST |
| Number of Total Expansion Bays | 60 |
| Number of 3.5" Bays | 60 |
| Hot Swappable Bays | Yes |
| Host Interface | Mini-SAS HD |
| Drive Interface | 12Gb/s SAS |
| Weight (Approximate) | 206.60 lb |
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| Height | 6.9" |
| Width | 16.7" |
| Depth | 38.7" |
| Cooling Fan | Yes |
| Limited Warranty | 5 Year |
| Total Hard Drive Capacity Supported | 600 TB |
| Total Hard Drive Capacity Installed | 360 TB |
| Number of Hard Drives Supported | 60 |
| Number of Hard Drives Installed | 60 |
