Tested and certified to operate with AirLink routers and gateways, the 6-in-1 SharkFin has a compact OEM style housing that contains 2x2 MiMo antenna function for 2G, 3G, and 4G LTE frequencies, and an active antenna for GNSS with 26dB gain LNA. Mounted via the integral SMA (f) mount, the portable antenna spans 2.4/5.0GHz and, the SharkFin offers dual band 3x3 MiMo Wi-Fi (2.4/5.0GHz) in a compact package.
Key Features
- Designed to operate at 698 MHz to 960 MHz operating frequency range
- Provides ease of management and installation thanks to its omni-direction feature
- Can be mounted as screw mount
- Operates at 26 dB gain
- Perfect to be used with cellular network
Dimensions
| Height | 4.8 inches |
|---|---|
| Width | 7.65 inches |
| Length | 14.25 inches |
| Weight | 2.98 pounds |
| Application/Usage | IoT Gateway |
| Application/Usage | Cellular Network |
| Application/Usage | GPS |
| Application/Usage | Wireless Data Network |
| Product Type | Antenna |
| Form Factor | Screw Mount |
| Brand Name | Sierra Wireless |
| Antenna Gain | 26 dB |
| Directivity | Omni-directional |
| Product Family | AirLink |
| Product Color | White |
| Product Type | Antenna |
| Manufacturer Part Number | 6001262 |
| Manufacturer Website Address | http://www.sierrawireless.com |
| Manufacturer | Sierra Wireless |
| Product Name | AirLink Antenna: 6-in-1 SharkFin |
| Product Line | AirLink |
| Brand Name | Sierra Wireless |
| Country of Origin | Vietnam |
| Weight (Approximate) | 2.83 lb |
| Form Factor | Screw Mount |
| Height | 4.65" |
| Width | 2.36" |
| Antenna Gain | 26 dB |
| Directivity | Omni-directional |
