The ACM7000-L Resilience Gateway ensures uptime at branch offices, retail stores, kiosks and other remote sites. Cellular access provides an always-on gateway to your off-site network devices, even when the primary network is down.
Identify and remediate issues at the network edge before they become failures with Smart OOB™. Maximize WAN resilience with Failover to Cellular™ to 4G LTE networks and built-in multicarrier capabilities.
- 4-8 serial ports, out-of-band management of network and server devices
- 4 x USB 2.0 console ports, out-of-band management of network and server devices
- Smart OOB extends beyond traditional out-of-band management
- Failover to Cellular™ and IP Passthrough for out-of-band access and failover network connectivity over cellular.
- Integrated RESTful API engine on devices running firmware 4.0 or higher
- Manage all edge routers, firewalls, UPSes, PDUs with serial & USB & Ethernet consoles
- Centralize the management of all your enterprise remote sites and data centers with Lighthouse 5
- Automatically detect and recover from outages and repair equipment faults
- Link Layer Discovery Protocol (LLDP) discover, identify and verify attached devices on your local network.
- Log audit trails to embedded 4GB local storage for troubleshooting and compliance
- Strong security, PCI DSS 3.2, FIPS140-2, SSL and SSH, stateful firewall, OpenVPN & IPsec
- Embedded internal temperature sensor
- Environmental and physical sensor alarm notification via SMS, SNMP or email
Key Features
- Smart OOB with Failover to Cellular
- Maintain network connectivity during failures with IP Passthrough
- Available with 4 port embedded switch
- Flexibility with built-in 4 USB console ports
- New highspeed global cellular modem - LTE-A Pro
- Built-in digital I/O and high voltage I/O
- Compact and powerful hardware with integrated 4 GB internal storage
Dimensions
| Height | 4.5 inches |
|---|---|
| Width | 7.65 inches |
| Length | 9.5 inches |
| Weight | 2.68 pounds |
| Application/Usage | Remote Management |
| Application/Usage | Remote Monitoring |
| Product Type | Infrastructure Management Equipment |
| Form Factor | Desktop |
| Form Factor | Rack Mount |
| Form Factor | Rail-mountable |
| Brand Name | Opengear |
| Product Family | ACM7000-L |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | Infrastructure Management Equipment |
| Manufacturer Part Number | ACM70082L |
| Manufacturer Website Address | http://www.opengear.com |
| Manufacturer | Opengear |
| Product Model | ACM7008-2-L |
| Product Name | ACM7000-L Resilience Gateway |
| Product Series | ACM7000-L |
| Brand Name | Opengear |
| Additional Information |
Models & Connectors:
Emissions: EN 55022:2010, CISPR 22:2008, FCC Part 15 Subpart B:2015, ICES-003 Issue 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008 Immunity: EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 Isolation:
Other Agency Approvals: CE, UL 1950, TUV, C-Tick, Security features to support PCI DSS 3.2 compliance, NERC CIP standards, FIPS 140-2 validated module Certificate #2473 Memory & CPU:
MTBF: AC-DC (12V) adapter - 100,000 hours Operating System: Linux with source code access and Custom Development Kit (CDK) Security & Authentication: IPsec & OpenVPN, SSL tunnels, Secure Shell (SSH V2), TACACS+, Kerberos, RADIUS and LDAP authentication, PAP/CHAP authentication (dial up), Dial back support, Local authentication, System event syslog, Authenticated NTP Gateway Router: Stateful firewall, DHCP server, DDNS, Port forwarding, IP filtering with access control lists
|
| Package Contents |
|
| Country of Origin | United States |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Weight (Approximate) | 1.32 lb |
| Height | 1.4" |
| Width | 5.1" |
| Depth | 4.7" |
| Limited Warranty | 4 Year |
