Product Overview
APC AP9567 Rack PDU Basic 2U is a powerful and convenient power distribution unit targeted at the IT facilities that require high-quality and consistent power. This PDU has been built considering the need to offer consistent power transmission in devices of servers, network components and storage centres, hence it is applicable in data centres and closets of the networks. With 12 IEC 320 C13 outlets and a 16A input current, it provides balanced power to multiple devices and lets keep its operations safe and efficient.
The AP9567 is configured so that it can be installed with ease in the rack-mount environment, where it can be mounted horizontally in 2U to give it flexibility in installation. Its strong style and plug-and-play architecture are good choices in the context of small to medium-scale implementations. As part of the family of trusted power management provided by APC, organisational performance, stability, and safety of mission-critical infrastructure are guaranteed over the long term.
Key Features
-
Reliable Power Distribution: It has a 16A maximum input current that provides reliable power to other devices simultaneously.
-
High Outlet Density: It has 12 IEC 320 C13 outlets, which enable a high rack utilisation and structural cabling.
-
Horizontal 2U Design: This is readily mounted in rack setups so that it is easily accessible.
-
Sustainable Construction: It is made with quality materials to guarantee the provision of the simplified data centre and enterprise needs.
-
Plug-and-Play Configurations: Time and the troublesome setup of the system are saved with a simple setup.
-
Better Safety: It has protection in a circuit to prevent overloads and ensure the safety of the equipment.
-
Power Management: This allows loading the devices connected to the power source efficiently and optimally.
-
Trusted Brand Assurance: Reciprocated by the global reputation of APC as a reliable partner in securing power and infrastructure.
Technical Specifications
|
Feature |
Specification |
|
Model |
APC AP9567 |
|
Product Type |
Rack PDU Basic |
|
Input Voltage |
208/230V AC |
|
Input Current |
16A |
|
Output Connections |
12 × IEC 320 C13 |
|
Mounting Type |
Rack-Mountable (2U, Horizontal) |
|
Rack Height |
2U |
|
Frequency |
50/60 Hz |
|
Cord Length |
8 ft (2.5 m) |
|
Maximum Power Capacity |
3.3 kVA |
|
Material |
Metal Enclosure |
|
Color |
Black |
|
Dimensions (H x W x D) |
3.5 x 17.6 x 4.5 in (Approx.) |
|
Weight |
7.5 lbs (Approx.) |
|
Part Number |
AP9567 |
