Product Overview
APC Back-UPS Pro BX1350M is an apt Uninterruptible Power Supply (UPS) that has a high performance to supply clean and continuous power to vital electronics. Having the capacity of 1350VA / 810W, this small tower UPS can protect home entertainment systems, gaming consoles, network equipment, and desktop computers against power issues, such as spikes and surges, as well as power outages. The Automatic Voltage Regulation (AVR) control system ultimately provides steady voltage to equipment connected to it, whilst the multifunction LCD delivers real-time feedback of the status of the device.
Key Features and Benefits
-
High Power Capacity: Provides 1350VA / 810W of power, which is ideal in safeguarding various devices when power is cut off.
-
Automatic Voltage Regulation (AVR): Regulates voltage changes, maintaining a constant power output and not using battery capacity.
-
Multifunction LCD Display: The display shows real-time information such as battery performance, load, and expected run time.
-
USB Charging Ports: It has two USB ports where mobile devices can be charged conveniently.
-
Surge Protection: Protects equipment connected to the system against spikes and power surges.
-
Minimalist Design: Small tower shape, fits well in the living room and office.
-
User-Replaceable Battery: Battery is easily replaced so that it can be used to increase the life of the UPS.
Technical Specifications
|
Feature |
Specification |
|
Capacity |
1350 VA / 810 W |
|
Topology |
Line-Interactive |
|
Output Voltage (Battery Mode) |
120V ±8% |
|
Output Waveform |
Simulated Sine Wave |
|
Input Voltage |
120V ±10% |
|
Frequency |
60 Hz ±3 Hz |
|
Power Factor |
0.6 |
|
Battery Type |
Sealed Lead-Acid (SLA) Maintenance-Free |
|
Battery Runtime (Full Load) |
Approximately 2.5 minutes |
|
Battery Runtime (Half Load) |
Approximately 10 minutes |
|
Recharge Time |
Approximately 16 hours |
|
Form Factor |
Tower |
|
Outlets |
10 x NEMA 5-15R (5 Battery Backup + 5 Surge) |
|
USB Ports |
2 x USB Type-A |
|
Data Ports |
1 x USB, 1 x RJ-45 (Network) |
|
Surge Energy Rating |
789 Joules |
|
Weight |
22.49 lbs (10.2 kg) |
|
Dimensions (WxDxH) |
9.84" x 3.94" x 15.04" (250 x 100 x 382 mm) |
|
Certifications |
UL1778, CSA C22.2 No. 107.3-05, FCC Class B |
|
Warranty |
3-year limited warranty |
Product Information
The APC Back-UPS Pro BX1350M is designed to deliver quality power protection, which is reliable, to the critical electronics. Its line-interacting topology will make sure that equipment connected to it is powered by clean and constant power with no interference with the power supply by voltage sags, surges, and electrical noise. The simulated sine wave output can be applied in the majority of electronic devices, and the AVR option can stabilize the fluctuation of voltages and does not involve battery power consumption, which prolongs the battery life.
The UPS is flexible in terms of installation because it has a compact tower design, which makes it compatible in different settings, such as home offices, small businesses, and entertainment centers. The multifunction LCD can also be used to monitor the UPS position, battery, and load status in real-time. The two USB ports are also convenient for charging mobile devices.
The BX1350M, with such features as surge protection, replaceable battery, and a 3-year warranty, ensures users that they can rely on the BX1350M to operate without interruption and a sense of security due to the matter of critical operation being handled by the UPS.
