Product Overview
The APC Smart-UPS SC500RM1U is a small and lightweight, line-interactive, uninterruptible power supply (UPS) developed to ensure dependable power security to minor IT devices in limited areas. This 1U rackmount UPS will provide simulated sine output, and its capacity is 500 VA /300 W; this means that delicate equipment will not interrupt its operations in the event of power spikes It can easily be installed in a shallow rack environment and so it can be implemented in edge environments, network closets, as well as small server rooms because of its short depth design.
Key Features and Benefits
-
Small Size: The 1U short package allows free use in small racks and thus conserves space.
-
Simulated Sine Wave Output: Stable power of connected equipment is provided, minimizing the risk of damage caused by power variations.
-
4 NEMA 5-15R Outlets: The outlets with battery backup and surge protection will provide a number of available outlets with which most devices can be connected.
-
Automatic Voltage Regulation (AVR): Makes use of minor voltage fluctuations without turning on the battery power, and saves battery life.
-
USB and Serial Connections: Allows connection with devices that will be used to receive measurements and be turned off.
-
ENERGY STAR(r) Certified: Strictly environmental and fully energy-efficient, it lowers operating expenses and contributes to the environment.
-
Two-Year Warranty: The warranty includes peace of mind since the UPS and battery have a two-year warranty (either as repairs or replacement).
Technical Specifications
|
Feature |
Specification |
|
Capacity |
500VA / 300W |
|
Topology |
Line-Interactive |
|
Waveform Type |
Simulated Sine Wave |
|
Input Voltage |
120V AC |
|
Output Voltage |
120V AC ±5% |
|
Frequency |
47–63 Hz |
|
Transfer Time |
4 ms typical |
|
Output Connections |
4x NEMA 5-15R outlets |
|
Input Connection |
NEMA 5-15P |
|
Form Factor |
Rackmount 1U |
|
Dimensions (H x W x D) |
1.7" x 17.0" x 10.6" (43 mm x 432 mm x 268 mm) |
|
Weight |
17.9 lbs (8.1 kg) |
|
Battery Type |
Valve-Regulated Lead-Acid (VRLA) |
|
Typical Recharge Time |
5 hours |
|
Warranty |
2-year limited warranty |
Product Information
APC Smart-UPS SC500RM1U is designed to deliver stable power security to the small IT equipment in space-tight locations. Its line interactive topology provides stable power to devices connected, and the output simulates a sine wave and is compatible with a wide variety of equipment.
This UPS has a short-depth 1U form factor and is therefore easily fit into a shallow rack design, suitable and well-suited in edge environments, network closets, or limited to a small server room. The 4 NEMA 5-15R outlets offer battery backup and surge protection to devices connected to them. The automatic voltage regulation (AVR) system also corrects slight voltage variations instead of switching to battery power, thus saving battery life.
There is available connectivity in the form of USB ports and serial ports to be able to communicate with the connected devices with an aim of monitoring as well as shutting down. ENERGY STAR(r) certification will guarantee the UPS to meet a set of rigorous energy efficiency standards, which result in minimizing operational costs and pollution.
APC Smart-UPS SC500RM1U has a two-year repair or replace warranty of the UPS and battery, which provides peace of mind and ensures that your vital business receives the necessary power protection.
