Product Overview
The APC SRT5KRMXLTUS is an online uninterruptible power supply (UPS) that offers high performance as well as a double conversion online power supply to ensure adequate and reliable power protection of critical IT infrastructure. Having 5.4kVA/4.8kW capacity, this 3U rackmount UPS is capable of providing pure sine wave output, which provides clean, stable power to delicate equipment. Its input and output voltage of 208 V makes it applicable in a myriad of applications such as servers, storage systems, and network devices. The UPS is a rack/tower convertible with flexible installation by integration into many environments.
Key Features and Benefits
-
Double-Conversion Online Technology: Converting incoming AC power to DC and back to AC, and providing a stable and constant output voltage, this technology offers continuous and high-quality power.
-
Pure Sine wave output: It provides clean and stable output to the delicate electronics to give the whole performance and the life span.
-
Rack / Tower Convertible Design: This design has a rail kit to be easily installed in a 3U rackmount and can be converted to a tower to enable flexible deployment.
-
Scalable runtime: This product supports a scalable runtime with up to 10 external battery packs (SRT192RMBPUS) to be able to continue running even when power is unavailable.
-
Network Management Card: It has a built-in network management card that can be used to remotely monitor and manage the system, whereby it can send real-time status information and alerts.
-
ENERGY STAR Certified: Meets high standards of energy efficiency, which minimizes the cost of operation and the environmental impact.
Technical Specifications
|
Feature |
Specification |
|
Capacity |
5.4kVA / 4.8kW |
|
Topology |
Double-Conversion On-Line |
|
Input Voltage |
208V AC ± 5% |
|
Output Voltage |
208V AC ± 5% |
|
Output Waveform |
Pure Sine Wave |
|
Transfer Time |
0 ms |
|
Outlets |
2 x L6-20R, 2 x L6-30R |
|
Battery Type |
Sealed Lead-Acid |
|
Extendable Runtime |
Supports up to 10 external battery packs (SRT192RMBPUS) |
|
Communication Ports |
USB, Serial, SmartSlot |
|
Dimensions (WxHxD) |
17.0" x 5.2" x 26.9" (432 mm x 132 mm x 683 mm) |
|
Weight |
90.8 kg (200.2 lbs) |
|
Warranty |
3 years (repair or replace) |
|
Compliance |
ENERGY STAR Certified, RoHS, CE, UL Listed |
Product Information
APC SRT5KRMXLTUS is designed to offer a quality and adequate supply of power protection to crucial electronic equipment. Two converting online topology is designed in such a way that connected equipment receives stable and clean power, and the pure sine wave output is compatible with sensitive electronics. Rack/ tower convertible design is also flexible in installation, and the long-run-time capability is provided to ensure that it continues to work when there is a prolonged power outage. Having an inbuilt network management card, users can manage and see the UPS remotely and get real-time status notifications and alerts. The server, storage systems, voice/data networks, medical laboratories, and light industrial usage will all be well served by this UPS.
