Product Overview
APC SMC1000C Smart-UPS is a line-interactive uninterruptible power supply (UPS) that is aimed to provide quality battery backup and surge protection to sensitive electronic equipment. Having a capacity of 1000VA/600W, this small tower UPS will guarantee an uninterrupted power supply in case of power outages and protect against the electricity changes, which is why it is recommended for home offices, small businesses, and IT professionals.
Key Features and Benefits
-
Line-Interactive Topology: Will adjust to slight variations in power automatically without switching to the battery, conserve battery life, and use less energy.
-
Pure Sine Wave Output: This is the smoother and even power that is compatible with sensitive electronics and prevents potential damage.
-
SmartConnect Cloud Monitoring: Unlimited remote monitoring and control using a web portal that gives the firms proactive alerts and automatic updates.
-
Automatic Voltage Regulation (AVR): Adjusts the voltage up or down to a fixed output to avoid exposure of corresponding equipment to under- and over-voltages.
-
Graphic LCD Display: Real-time status and diagnostics, and the user can monitor UPS performance and battery health on one display.
-
Small Size: Tower form factor design is a space-aware design that can be easily mounted into the home or office space and does not need to be mounted in a rack.
-
ENERGY STAR Certified: Meets the high energy efficiency standards, which conserves the cost and environmental impact of the operations.
Technical Specifications
|
Feature |
Specification |
|
Capacity |
1000VA / 600W |
|
Topology |
Line Interactive |
|
Output Waveform |
Pure Sine Wave |
|
Input Voltage |
120V AC ± 10% |
|
Output Voltage |
120V AC ± 10% |
|
Output Frequency |
50/60Hz ± 3Hz (synchronized to mains) |
|
Outlets |
8 x NEMA 5-15R |
|
Input Connection |
NEMA 5-15P |
|
Battery Type |
Sealed Lead-Acid |
|
Battery Voltage |
12V |
|
Battery Modules Included |
1 |
|
Recharge Time |
Approximately 3 hours |
|
Extended Runtime |
Supports external battery packs (sold separately) |
|
SmartConnect |
Yes (cloud-based monitoring) |
|
Communication Ports |
USB, Serial, SmartConnect Ethernet Port |
|
Management Software |
PowerChute Serial Shutdown |
|
Audible Noise Level |
40 dBA at 1 meter |
|
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
|
Storage Temperature |
-15°C to 45°C (5°F to 113°F) |
|
Operating Humidity |
0% to 95% (non-condensing) |
|
Operating Elevation |
0 to 10,000 ft (0 to 3,000 meters) |
|
Dimensions (WxHxD) |
5.4" x 6.3" x 14.5" (137 mm x 161 mm x 368 mm) |
|
Weight |
18.5 lbs (8.4 kg) |
|
Warranty |
2 years (repair or replace) |
|
Compliance |
ENERGY STAR Certified, UL1778, cUL, CSA C22.2, FCC Class A |
Product Information
APC SMC1000C Smart-UPS is designed to offer reliable protection of sensitive electronic devices in terms of power. Its line-interactive topology allows it to operate continuously in case of power upsets, and its pure sine wave output is compatible with a broad collection of devices. The UPS has eight NEMA 5-15R ports, which give plenty of connections to several devices. Increased efficiency of operations is provided by the SmartConnect cloud portal through remote monitoring, proactive alerts, and firmware updates. It is small in terms of tower shapes, which are easily integrated into different environments. ENERGY STAR certification provides an operation that is energy-efficient, which makes it easier and less harmful to the environment in terms of cost.
