Product Overview
Cisco Catalyst C9200CX-12P-2X2G-E is a small and fanless Layer 3-controlled switch intended for enterprise access networks. It has 12 Gigabit Ethernet ports with Power over Ethernet Plus (PoE+) capability, two 10 Gigaflex SFP+ uplink ports, and two 1 Gigaflex copper uplink ports. It has a PoE + budget of 240W; therefore, it is effective in powering the related devices like IP phones, wireless access points and security cameras. The switch has an internal power supply of 315W AC and this is recommended to be used in space and noise-sensitive settings.
Key Features and Benefits
-
Small Size and Fanless Design: The fanless design makes the architecture quiet in operation and therefore can work in environments where noise is sensitive.
-
Large PoE+ Power Budget: Supplies up to 240W of PoE+ power, which is compatible with a large variety of powered devices.
-
Flexible Uplink: Two 10G SFP+ and two 1G copper uplink ports, with a choice of versatile connectivity.
-
Layer 3 Features: Layer 3 features (static routing, RIP, and other Layer 3 features) enable effective traffic management.
-
Greater Security: 802.1X authentication, ACLs and DHCP snooping are some of the features that enhance the security of the network.
-
Energy Saving: It meets IEEE 802.3az Energy Efficient Ethernet requirements, which minimize energy use.
Technical Specifications
|
Feature |
Specification |
|
Model |
Cisco Catalyst C9200CX-12P-2X2G-E |
|
Ports |
12 × 10/100/1000 Ethernet (PoE+), 2 × 10G SFP+, 2 × 1G Copper Uplink |
|
PoE+ Power Budget |
240W |
|
Switching Capacity |
68 Gbps |
|
Forwarding Rate |
50.59 Mpps |
|
Power Supply |
Internal 315W AC |
|
Form Factor |
1U Rackmount, Fanless |
|
Dimensions (WxDxH) |
17.3 × 10.6 × 9.6 inches (43.9 × 26.9 × 24.4 cm) |
|
Weight |
6.6 lbs (2.99 kg) |
|
Management |
Cisco IOS XE, Web UI, CLI |
|
Security Features |
802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection |
|
Licensing |
Requires Cisco DNA Essentials license |
Product Information
The Cisco Catalyst C9200CX-12P- 2X2G-E is designed to address the needs of the contemporary enterprise network. It is fanless and small enough to be used in space-constrained and noisy environments. Having 12 PoE+ ports, it is able to supply power to numerous different devices, avoiding the use of additional sources of power and making the installations easier.
The multi-layered functions of the switch (Layer 3) allow it to handle traffic effectively and its security performance ensures that the network is not subjected to unwarranted access and unauthorized interference. The flexible uplink solutions make it compatible with all network topologies and the design is energy efficient to lower the operational cost.
Cisco Catalyst 9200 Series, C9200CX-12P-2X2G-E, provides protection to investment and supports any future software development and integration in already existing Cisco networks.
