Cisco C9300-24S-E Catalyst 9300 Series Switch is a managed switch, Layer 3 enterprise-level switch created to provide high-speed and high quality, reliability, and scalability to networks in the current times. It is based on Cisco next-generation skeleton of Catalyst 9300 Series and has a Gigabit Ethernet connection 24 SFP (fiber) ports which are effectively utilized in fiber aggregation and distribution in areas of high density. It is designed as a Cisco StackWise-480 technology that enables stacking up to 480 Gbps bandwidth to provide smooth scalability and easy management of more than one switch.
The C9300-24S-E uses Cisco IOS XE Software which offers high security capability, programmability and automations. Its Network Essentials feature package comprises of QoS, Layer 3 routing; multicast features to facilitate the best performance in business networks. This switch has an uplink that is modular, redundancy in fans and power supplies which gives high availability and operational resiliency to very vital business applications.
Key Features:
-
24 SFP Ports: Gigabit Ethernet ports based on the fiber are available to provide fast and reliable network connecting capabilities to enterprise network.
-
Layer 3 Managed Switch: Provides layer 3 routing, segmentation and traffic controls.
-
StackWise-480 Technology: Scales stacking bandwidth at up to 480 Gbps with easy scalability.
-
Cisco IOS XE Software: The support is programmable, auto-configurable, and more secure.
-
Network Essentials License: This consists of fundamental services in the network such as QoS, Layer 3 routing, and multicast.
-
Redundant Power and Cooling: Helps in providing optimum uptime and business continuity.
-
High Security Standards: TrustSec, MACsec encryption and Threat defense network protection features.
-
Energy Efficient: Operates at low costs always ensuring high performance and reliability.
-
1U Rack-Mountable Design: Data center and enterprise rack-mountable.
Technical Specifications:
|
Feature |
Specification |
|
Brand |
Cisco |
|
Model |
C9300-24S-E |
|
Series |
Catalyst 9300 Series |
|
Product Type |
L3 Managed Network Switch |
|
Port Configuration |
24 x SFP (Gigabit Ethernet) |
|
Stacking Bandwidth |
Up to 480 Gbps (StackWise-480) |
|
Uplink Options |
Modular (Network Modules Supported) |
|
Switching Capacity |
128 Gbps |
|
Forwarding Rate |
95.2 Mpps |
|
Software License |
Network Essentials |
|
Operating System |
Cisco IOS XE |
|
MAC Address Table |
32,000 entries |
|
DRAM |
8 GB |
|
Flash Memory |
16 GB |
|
Network Security |
MACsec, TrustSec, ACLs, Dynamic ARP Inspection |
|
Power Supply |
Dual redundant (optional) |
|
Cooling System |
Redundant fans |
|
Form Factor |
1U Rack-Mountable |
|
Dimensions (H x W x D) |
1.73 x 17.5 x 17.5 in |
|
Weight |
12.8 lbs (Approx.) |
|
Warranty |
Limited Lifetime Warranty |
