Product Overview
Cisco Catalyst C1300-8T-E-2G is an enterprise-class Gigabit Ethernet switch that is compact, fast and secure to provide high-performance connectivity to the small business as well as to the branch offices and the lean IT environments. This model has 8 Gigabit copper ports and 2 Gigabit combo uplinks that feature flexible deployment with an easy but robust management experience. It is a fanless design that will operate silently, an energy-efficient architecture will assist in saving power, is thus cost-effective and environment friendly.
Key Features and Benefits
-
Enterprise-Grade Performance - Take advantage of 20 Gbps of switching and wire-speed forwarding up to 14.88 Mpps of data transfer, which is needed to perform as reliably and with low latency as the enterprise needs.
-
Simplified Management - Control your network by using a simple web interface, CLI, SNMP, or Cisco Business Dashboard. The integration of mobile apps allows IT teams that are otherwise constrained by resources to make the deployment and monitoring processes simple.
-
Secure Networking: Built-in Layer 3 capabilities such as VLAN segmentation, IPv6 first-hop security, and ACL ensure that critical business traffic is secure and enforces access policy.
-
Quality operation - Fanless design and low-power consumption (about 10.6 W) minimizes operational costs and noise, which makes the design best suited to offices and branch locations.
-
Small size, Rugged Design - Small size, rack-mount capability and external power: Our compact size makes performance in our different deployment environments consistent and predictable.
Technical Specifications
|
Feature |
Specification |
|
Model |
Cisco Catalyst C1300-8T-E-2G |
|
Network Ports (Downlink) |
8 × 10/100/1000Base-T RJ-45 ports |
|
Uplink Ports |
2 × Gigabit RJ-45/SFP combo ports |
|
Switching Capacity |
20 Gbps (non-blocking) |
|
Forwarding Rate |
Up to 14.88 Mpps (64-byte frames) |
|
PoE Support |
None (data-only switch) |
|
Management Options |
Web UI, CLI, SNMP, Cisco Business Dashboard, Mobile App |
|
Form Factor / Dimensions |
Rack-mountable; 268 × 185 × 44 mm |
|
Weight |
Approx. 1.39 kg |
|
Power Supply |
External, AC 110–240 V |
|
Power Consumption |
~10.6 W (typical, non-PoE) |
|
Operating Temperature |
-5°C to +50°C |
|
Storage Temperature |
-25°C to +70°C |
|
Operating Humidity |
10–90% RH, non-condensing |
|
Compliance / Certifications |
UL, CE, FCC; Cisco Enhanced Limited Lifetime Hardware Warranty |
Product Information
The switch is designed to operate silently, and it has a fanless design that allows it to be deployed around noisy places such as offices and in retail outlets. The small size of the product and its rack-mountable shape enable the integration with the existing network devices without any complications. The C1300-8T-E-2G is a well-considered option as an organization intending to achieve quality Gigabit connections on a large scale, enabling its operations with the assistance of Layer 3 facilities, easy-to-use managerial tools, andan emphasis on efficiency and security.
