Product overview
Cisco Catalyst C9300X-24Y-E is a 25G processor-based switch with high switching capacity designed to support the current campus aggregation and high-density accessibility layers. Having twenty-four SFP28 ports that support 1/10/25-gigabit optics, it has the headroom needed by Wi-Fi 6/6E backhaul, server uplinks, and bandwidth-intensive AV/IoT networks, as well as the low-latency and non-blocking forwarding of stack-wide.
The 9300X platform, a member of the Catalyst 9000 family, is a hardware-grounded security platform with rich Layer 3 services and operations automation-ready. Network Essentials software contained in the -E bundle consists of the foundational routing, segmentation and policy. StackWise stacking, MACsec and telemetry APIs assist you to scale safely and work with confidence across campus and branch locations.
Key features
-
24 ports of SFP28 fiber with 1/10/25G dual/tri-rate.
-
Flexibility High-speed uplink (40/100G) QSFP (model/optic flexible)
-
Core L2/L3 features and segmentation Network Essentials software.
-
Scale and monolithic management (high stack bandwidth) StackWise stacking.
-
802.1X, trust/segmentation, and MACsec (license/optic) capability (enterprise security).
-
Automation & visibility through model-driven telemetry and open APIs.
-
Field-replaceable power supplies and fans in a chassis of 1RU size.
Technical specifications
|
Category |
Details |
|
Model |
C9300X-24Y-E |
|
Series |
Cisco Catalyst 9300X |
|
Downlink ports |
24 × SFP28 supporting 1/10/25G (optic dependent) |
|
Uplinks |
High-speed QSFP options up to 40/100G (model/optic dependent) |
|
Software bundle |
Network Essentials (–E) |
|
Switching performance |
Wire-speed, non-blocking Layer 2/Layer 3 forwarding |
|
Stacking |
StackWise stacking; high stack bandwidth with single-point management |
|
Security |
802.1X, ACLs, DHCP Snooping, Dynamic ARP Inspection; MACsec capable (license/optic dependent) |
|
QoS |
Hardware QoS with per-port classification, queuing, policing, and shaping |
|
Management & APIs |
CLI, web UI, SNMP; NETCONF/RESTCONF, gNMI; model-driven telemetry; zero-touch onboarding options |
|
Power |
Dual, hot-swappable PSUs (redundancy supported) |
|
Cooling |
Field-replaceable fan modules; front-to-back airflow (model dependent) |
|
Form factor |
1RU rack-mount chassis |
|
Typical use cases |
Campus aggregation, high-density fiber access, Wi-Fi 6/6E AP backhaul, server/edge uplinks |
