The Cisco 10GBASE-ZR module supports link lengths of up to about 80 kilometers on standard SMF (G.652). This interface is not specified as part of the 10 Gigabit Ethernet standards and is, instead, built according to Cisco specifications. SFP-10G-ZR-S does not support FCoE.
Specifications
| Network | |
|---|---|
| SFP transceiver type | Fiber optic |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 Mbit/s |
| Performance | |
| Hot-swap | Yes |
| SFP transceiver type | Fiber optic |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 Mbit/s |
| Maximum transfer distance | 3149606.3" (80000 m) |
| Wavelength | 1550 nm |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Tx power (max) | 4 dBmW |
| Rx power (min) | 24 dBmW |
| Rx power (max) | -7 dBmW |
| Single-mode fiber (SMF) supported | Yes |
| SFP transceiver standard | ZR |
| Features | |
| Hot-swap | Yes |
| Certification | MSA |
| Power | |
| Power consumption (typical) | 1.5 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 85% |
| Weight & dimensions | |
| Width | 0.528" (13.4 mm) |
| Depth | 2.22" (56.5 mm) |
| Height | 0.335" (8.5 mm) |
| Weight | 2.65 oz (75 g) |
| Certificates | |
| Certification | MSA |
