This Cisco® Meraki MA-SFP-10GB-LRM compatible SFP+ transceiver provides 10GBase-LRM throughput up to 220m over multi-mode fiber (MMF) using a wavelength of 1310nm via an LC connector. It is guaranteed to be 100% compatible with the equivalent Cisco® Meraki transceiver. This easy to install, hot swappable transceiver has been programmed, uniquely serialized and data-traffic and application tested to ensure that it will initialize and perform identically. Digital optical monitoring (DOM) support is also present to allow access to real-time operating parameters. This transceiver is Trade Agreements Act (TAA) compliant. We stand behind the quality of our products and proudly offer a limited lifetime warranty.
Key Features
- Duplex LC connector
- Support hot-pluggable
- Metal with lower EMI
- Excellent ESD protection
- DFB Transmitter and PIN Receiver
- Distance up to 10km on 9/125um SMF
- Single 3.3V power supply and Low power dissipation <1.2W
- GR-253-CORE compliant
- RoHS Compliant and Lead-Free
- Compliant with IEEE 802.3ae
- Compliant with SFP+ MSA: SFF-8431 Rev4.1
- Compliant with SFF-8472 Rev.11.0
- Digital diagnostic compatible with SFF-847 Rev11.0
Dimensions
| Height | 1 inches |
|---|---|
| Width | 2 inches |
| Length | 4.5 inches |
| Weight | 0.15 pounds |
| Product Type | SFP+ |
| Network Technology | 10GBase-LRM |
| Brand Name | AddOn |
| Country of Origin | United States |
| Maximum Data Transfer Rate | 10 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Total Number of Ports | 1 |
| Product Type | SFP+ |
| Manufacturer Part Number | MA-SFP-10GB-LRM-AO |
| Manufacturer Website Address | http://www.addoncomputer.com |
| Manufacturer | AddOn |
| Product Name | SFP+ Module |
| Brand Name | AddOn |
| Interfaces/Ports Details | 1 x LC 10GBase-LRM Network |
| Total Number of Ports | 1 |
| Network Technology | 10GBase-LRM |
| Maximum Data Transfer Rate | 10 |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Compatibility |
|
| Country of Origin | United States |
| Weight (Approximate) | 0.40 lb |
| Height | 0.4" |
| Width | 0.6" |
| Depth | 2.2" |
