Product Overview
CyberPower OL2200RTXL2U is an online Uninterruptible Power Supply (UPS) that is high-performance, uses a 2U casing to house the equipment, and employs two sources of conversion to improve both reliability and power delivery to highly sensitive IT equipment. Having the capacity of 2200 VA / 1800 W, and delivering pure sine wave output, this 2U rackmount/tower convertible UPS provides servers, network devices, and storage systems, and telecommunications equipment with protection against power disturbances, including spikes, surges, and outages. The flexible design enables it to be installed easily in both rack mount and tower configurations, where it is used optimally in enterprise settings as well as in data centers.
Key Features and Benefits
-
Double-Conversion Topology: Provides uniform, clean, and almost perfect power, irrespective of the state of the power supplied.
-
Pure Sine Wave Output: Provides pristine power that is stable to ensure the best performance and life expectancy of sensitive equipment.
-
Adjustable Output Voltage: Provides flexibility in the set output voltage of 100 V, 110 V, 115 V, 120 V, and 125 V, plus or minus 2%.
-
Fast Charge Technology: Recovers complete backup power within a shorter period of time, reducing downtime when there is an outage.
-
Long LCD Control Panel: This will provide real-time data on UPS status, battery, and load status so that the status can easily be traced.
-
Intelligent Battery Management: Smart battery management: Performance and long battery life through advanced battery charging.
-
GreenPower UPS ™ ECO Mode: Saves energy use and operating expenses through efficiency.
-
Generator Compatibility: In compatibility with generator power sources.
-
Surge Protection: Insulates equipment to which a circuit is connected against surges and power spikes.
-
Extensive Warranty: It will also come with a 3-year warranty and a 400,000 Connected Equipment Guarantee in case something goes wrong.
Technical Specifications
|
Feature |
Specification |
|
Capacity |
2200 VA / 1800 W |
|
Topology |
Double-Conversion Online |
|
Output Voltage (Configurable) |
100V, 110V, 115V, 120V, 125V ±2% |
|
Output Waveform |
Pure Sine Wave |
|
Input Voltage |
120V ±2% |
|
Frequency |
50/60 Hz ±3 Hz |
|
Power Factor |
0.82 |
|
Battery Type |
Valve Regulated Lead-Acid (VRLA) |
|
Battery Runtime (Half Load) |
Approximately 21 minutes |
|
Battery Runtime (Full Load) |
Approximately 8 minutes |
|
Recharge Time |
Approximately 4 hours |
|
Form Factor |
2U Rack/Tower Convertible |
|
Outlets |
6 x NEMA 5-20R, 1 x NEMA L5-20R |
|
Input Connection |
NEMA L5-20P with 5-20P Adapter, 10 ft. cord |
|
Surge Protection |
1335 joules |
|
Weight |
68.2 lbs (30.9 kg) |
|
Dimensions (WxDxH) |
17.2" x 19.0" x 3.5" (437 x 483 x 89 mm) |
|
Certifications |
UL1778, CSA C22.2 No. 107.3-05, FCC Class B |
|
Warranty |
3-year limited warranty |
|
Connected Equipment Guarantee |
$400,000 |
Product Information
The CyberPower OL2200RTXL2U is developed to deliver high-quality and reliable power protection to the critical IT infrastructure. Its dual conversion topology will mean that equipment connected to it will receive, clean, and stable power without the interference of electrical issues like voltage dips, voltage surges, or electrical noise. The low-noise sine wave output is handy when using sensitive devices, such as servers and networking equipment, and this needs consistent power to perform optimally.
The UPS is friendly to different settings as it is flexible in its 2U rackmount design that can be installed in any setting, such as data centers, server rooms, and telecommunications facilities. The LCD control panel is extendable in nature and enables real-time monitoring, whereas the Smart Battery Management system optimizes the battery performance and the life of the battery.
The OL2200RTXL2U has such features as generator compatibility and surge protection to provide continuous operation even when there is a problem with the power supply. Its low-energy usage design helps reduce operating costs, and the all-inclusive warranty and large Connected Equipment Guarantee give the end-users a sense of security when having to rely on the UPS to run critical processes.
