Product overview
CyberPower PDU41002 It is a vertical 0U, switched metered-by-outlet power distribution unit designed to fit dense 120-volt racks. It provides per-outlet control and per-outlet metering of energy, and thus you can remotely re-boot hung devices, stage power-up sequences, and monitor all the points of power expenditure, right down to the receptacle. The accuracy makes it suitable in colocation, edge closets and labs where rapidity and responsibility are uncompromising.
The unit is designed to be easily deployed and has a locking 20amp input, 24 NEMA 5-20R output points, built-in network management (web, SNMP, CLI) and an environmental sensor port that can support temperature/humidity sensors. A 0U profile and tool-less button mounts save rack space and user-configurable alarms assist in preventing overloads before they draw a breaker.
Key features
-
0U vertical with 24 outlets that are switchable individually.
-
chargeback and capacity planning per-outlet (current, energy) metering.
-
Remote restart and programmed boot/shut and outlet grouping.
-
Web, SNMP and CLI network management; logging and alerts.
-
Email/SNMP traps and users set thresholds to avoid overloads.
-
Port of environmental monitoring of temperature/humidity probe.
-
Heavy metal casing with cord holding plates and bright labeling.
Technical specifications
|
Category |
Details |
|
Model |
PDU41002 |
|
Type |
Switched, metered-by-outlet rack PDU |
|
Form factor |
0U vertical (Zero-U); tool-less button-mount capable |
|
Input voltage |
100–120 V single-phase |
|
Maximum current |
20 A |
|
Input plug |
NEMA L5-20P |
|
Power cord |
Approximately 10 ft (model dependent) |
|
Outlets |
24 × NEMA 5-20R, individually switchable |
|
Metering |
Per-outlet and aggregate monitoring (A, W, kWh) |
|
Control |
Outlet-level on/off, reboot, locking, and sequencing; outlet groups |
|
Network & management |
Ethernet management; web UI, SNMP, CLI; firmware upgradable |
|
Alarms & notifications |
User-defined thresholds with email/SNMP traps; event logs |
|
Environmental sensing |
Port for external temperature/humidity probe (optional accessory) |
|
Mounting hardware |
Button-mount kit and brackets for standard 19″ cabinets |
|
Dimensions (H × W × D) |
~70 in × 2.2 in × 1.8 in (approximate) |
|
Weight |
~12 lb (approximate) |
|
Operating environment |
Indoor IT racks and network closets |
|
Typical use cases |
Remote reboot, chargeback metering, capacity planning, edge and colocation racks |
