Improve application efficiency and network performance with innovative and versatile capabilities that optimize high-performance server workloads such as NFV, storage, HPC-AI and hybrid cloud.
Performance for Cloud Applications
Delivers the bandwidth and increased application throughput required for demanding cloud workloads including edge services, web servers, database applications, caching servers, and storage targets.
- Application Device Queues (ADQ) improves application response time predictability using advanced traffic-steering technology
- Dynamic Device Personalization (DDP) enhances packet classification capabilities, to deliver up to 3x throughput improvement for some cloud workloads
- Supports both RDMA iWARP and RoCEv2 for high-speed, low-latency connectivity to storage targets
Optimizations for Communications Workloads
Provides packet classification and sorting optimizations for high-bandwidth network and communications workloads, including mobile core, 5G RAN, and network appliances.
- Dynamic Device Personalization (DDP) supports existing and new communications-specific protocols improving packet-processing efficiency up to 3x for some Network Functions Virtualization (NFV) workloads
- IEEE 1588 Precision Time Protocol (PTP) v2enables precise clock synchronization across the 5G RAN deployments
- Enhanced Data Plane Development Kit (DPDK) support increases packet-processing speeds
Versatile Port Configurations with EPCT
E810-CQDA1 and -CQDA2 adapters support a wide range of system configurations to meet customer needs and workload requirements. The many port and speed combinations available simplify validation and deployment. Using EPCT, these adapters can be programmed to act as many different physical network adapters, with a maximum throughput of 100Gbps.
All 800 Series products include these technologies | Greater Predictability at Scale
As modern data centers scale, a key challenge is to provide scalable, predictable application-level performance. Application Device Queues (ADQ) technology improves performance scalability and predictability by dedicating queues to key workloads, delivering predictable high performance through dramatically reduced jitter.
Key Features
- Single and Dual-Port QSFP28
- PCI Express (PCIe) 4.0 x16
- Ethernet Port Configuration Tool (EPCT)
- Application Device Queues (ADQ)
- Dynamic Device Personalization (DDP)
- Supports both RDMA iWARP and RoCEv2
Dimensions
| Height | 1.25 inches |
|---|---|
| Width | 5.75 inches |
| Length | 9 inches |
| Host Interface | PCI Express 4.0 x16 |
| Product Type | 100Gigabit Ethernet Card |
| Device Supported | Server |
| Form Factor | Plug-in Card |
| Network Technology | 100GBase-X |
| Brand Name | Intel |
| Expansion Slot Type | QSFP28 |
| Maximum Data Transfer Rate | 100 Gbit/s |
| Product Family | 800 |
| Total Number of Ports | 2 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | 100Gigabit Ethernet Card |
| Manufacturer Part Number | E810CQDA2 |
| Manufacturer Website Address | http://www.intel.com |
| Manufacturer | Intel Corporation |
| Product Model | E810-CQDA2 |
| Product Name | Ethernet Network Adapter E810-CQDA2 |
| Product Series | 800 |
| Brand Name | Intel |
| Expansion Slot Type | QSFP28 |
| Host Interface | PCI Express 4.0 x16 |
| Total Number of Ports | 2 |
| Media Type Supported | Optical Fiber |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Network Technology | 100GBase-X |
| Form Factor | Plug-in Card |
| Product Color | Green |
| Bracket Height | Low Profile |
| Color Family | Green |
| Chipset Manufacturer | Intel |
| Chipset Model | E810-CAM2 |
