Product Overview
The Fortinet FortiGate 40F with UTP Bundle (FG-40F-BDL-950-12) is a compact yet powerful next-generation firewall switch designed to meet the requirements of small businesses, branch offices, and distributed enterprises that require enterprise-level protection in a smaller form factor. This package provides 1 year of FortiGuard Unified Threat Protection (UTP) and FortiCare support, offering superior security services including intrusion prevention, anti-malware, web filtering, and application control, which are easily administered through FortiOS. The FG-40F features a fanless design, high throughput, and an SD-WAN, delivering a high level of reliable performance and strong defense without excessive complexity.
Key Features and Benefits
Security, a One-Stop Solution
Defends against a broad set of cyber threats with FortiGuard UTP, such as IPS, anti-malware, URL filtering, and application control.
High-Performance Firewalling
Provides up to 5 Gbps firewall throughput and 600 Mbps threat protection throughput, ensuring quality and secure connectivity, even with advanced inspection enabled.
Streamlined the SMB and Branch office optimization
The fact that it has a desktop-friendly design, is quiet because it has no fans, and is perfect in office settings where space and noise are of significance.
Secure Remote Connectivity
Accommodates both 4.4 Gbps IPsec VPN throughput and 490 Mbps SSL-VPN throughput in support of rapid, secure remote access and branch connection.
Learning SD-WAN Capabilities
Streamlines WAN functions and in-built SD-WAN to provide cost-efficient connection and enhanced application performance.
Scalable Session Handling
Supports heavy user and device usage with multiple users and supports up to 700,000 simultaneous sessions and 35,000 new sessions per second.
Technical Specifications
|
Feature |
Specification |
|
Model / Bundle |
FortiGate 40F with 1-Year FortiGuard UTP + FortiCare (FG-40F-BDL-950-12) |
|
Firewall Throughput (IPv4) |
5 Gbps |
|
NGFW Throughput (Enterprise Mix) |
800 Mbps |
|
Threat Protection Throughput |
600 Mbps |
|
IPsec VPN Throughput |
4.4 Gbps |
|
SSL-VPN Throughput |
490 Mbps |
|
Concurrent Sessions (TCP) |
700,000 |
|
New Sessions per Second |
35,000 |
|
VPN Tunnels (IPsec Gateway-to-Gateway) |
Up to 200 |
|
Virtual Domains (VDOMs) |
Up to 10 |
|
Interfaces |
5x GE RJ-45 (WAN/Internal), USB, Console RJ-45 |
|
Form Factor |
Desktop / Wall-Mountable, Fanless |
|
Power Consumption |
~16–19 W (typical use) |
Product Information
FortiGate 40F UTP Bundle ( FG-40F-BDL-950-12 ) offers the security of Fortinet at the enterprise level with ease and low cost that small companies and branch offices need. It is based on FortiOS and combines firewalling, SD-WAN, threat intelligence, and VPN into a single appliance, easily deployable and easily managed.
This package facilitates the organizations to operate at a safe level with not only the hardware, but also security services. The FortiGuard UTP and FortiCare 12-month support ensure protection against changes in threats and the presence of expert technical support in case of need. It is a well-known, quiet device in office environments, thanks to its fanless, low-power design and high-throughput capabilities, which enable it to grow as the business expands.
