The Aruba CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. Created for game-changing operational efficiency with built-in analytics and automation, the CX 6200 switches provide an enterprise-class access layer solution that's simple and secure.
Built from the ground up with a combination of cuttingedge hardware, software and analytics and automation tools, the stackable CX 6200 switches are part of the Aruba CX switching portfolio. By combining a modern, fully programmable OS with the Aruba Network Analytics Engine, the CX 6200 brings industry leading monitoring and troubleshooting capabilities to the access layer.
A powerful Aruba Gen7 ASIC architecture delivers reliable performance and enterprise-class feature support with flexible programmability for tomorrow's applications. The CX 6200 is designed for simple deployment using the intuitive Aruba CX Mobile App that speeds install, configuration and stacking of up to 8 switches. The CX 6200 switch series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high-speed uplinks. Fixed switches support up to 30W of PoE per port. Flexible, modular switches offer hotswappable power supplies and fans for enhanced resiliency and redundancy, and up to 60W of PoE per port to power the latest IoT devices, security cameras, and wireless APs.
Aruba Dynamic Segmentation extends Aruba's foundational wireless role-based policy capability to Aruba wired switches. What this means is that the same security, user experience and simplified IT management can be enjoyed throughout the network. Regardless of how users and IoT devices connect, consistent policies are enforced across wired and wireless networks, keeping traffic secure and separate.
PRODUCT DIFFERENTIATORS | AOS-CX - a modern software system
The Aruba CX 6200 Switch Series is based on AOS-CX, a modern, database-driven operating system that automates ARUBA CX 6200 SWITCH SERIES and simplifies many critical and complex network tasks. A built-in time series database enables customers and developers to utilize software scripts for historical troubleshooting, as well as analysis of past trends. This helps predict and avoid future problems due to scale, security, and performance bottlenecks. Easy access to all network state information allows unique visibility and analytics Our AOS-CX software also includes Aruba Network Analytics Engine (NAE) and support for Aruba NetEdit. Because AOSCX is built on a modular Linux architecture with a stateful database, our operating system provides the following unique capabilities:
- Easy access to all network state information allows unique visibility and analytics
- REST APIs and Python scripting for fine-grained programmability of network tasks
Key Features
- Supports layer 3 switching for enhanced performance and usability
- Rack mounting enables you to organize wires & secure cables for professional installation
- Management capability allows maximum efficiency and with unrestricted control
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Twisted Pair media support for efficient and reliable connectivity
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 48.0 ports
- Effectively increases available bandwidth on your network
- Comes in gray color for a sophisticated and dazzling look
Dimensions
| Height | 4.7 inches |
|---|---|
| Width | 18.7 inches |
| Length | 22.3 inches |
| Weight | 16 pounds |
| Product Type | Ethernet Switch |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Form Factor | Surface Mount |
| Form Factor | Rack-mountable |
| Form Factor | Cabinet Mount |
| Power Consumption | 76 W |
| Brand Name | Aruba |
| Expansion Slot Type | SFP |
| Manageable | Yes |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | Gigabit Ethernet |
| Product Family | CX 6200 |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 48.0 |
| Total Number of Expansion Slots | 4.0 |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | JL728B#ABA |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Model | JL728B |
| Product Name | CX 6200F 48G Class 4 PoE 4SFP+ 740W Switch |
| Product Series | CX 6200 |
| Brand Name | Aruba |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 4 |
| Shared SFP Slot | Yes |
| Total Number of Expansion Slots | 4.0 |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 48.0 |
| Port/Expansion Slot Details | 4 x 10Gigabit Ethernet Expansion Slot |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet Network |
| Manageable | Yes |
| Network Technology | 10GBase-X |
| Network Technology | 10/100/1000Base-T |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Layer Supported | 3 |
| Weight (Approximate) | 11.31 lb |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 12.9" |
| Compatible Rack Unit | 1U |
| Product Color | Gray |
| Color Family | Gray |
| PoE Budget | 740 W |
