HPE ProLiant MicroServer Gen10 Plus v2 server with one Intel Pentium G6405 processor, 16 GB memory, four large form factor non-hot plug drive bays, and a 180W external power supply
Key Features
- Compute: Intel® Xeon® E-2314 Processor and Intel® Pentium® G6405 Processor.
- Memory: ECC, UDIMM DDR4, and 3200 MT/s (64 GB maximum).
- PCIe expansion: PCIe Gen4.
- Storage controller: Intel VROC SATA software RAID.
Dimensions
| Height | 9 inches |
|---|---|
| Width | 14.25 inches |
| Length | 18 inches |
| Weight | 13.7 pounds |
| Product Type | Server |
| Maximum Memory Supported | 64 GB |
| Standard Memory | 16 GB |
| Chipset | Intel C252 |
| Form Factor | Ultra Micro Tower |
| Processor Speed | 4.10 GHz |
| Processor Type | Pentium Gold |
| Controller Type | Serial ATA/600 |
| Brand Name | HPE |
| Memory Technology | DDR4 SDRAM |
| Processor Model | G6405 |
| Processor Core | Dual-core (2 Core) |
| Environmentally Friendly | Yes |
| Redundant Power Supply | No |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Ethernet Technology | Gigabit Ethernet |
| VGA | Yes |
| Maximum Power Supply Wattage | 180 W |
| DisplayPort | Yes |
| Product Family | ProLiant MicroServer Gen10 Plus v2 |
| Limited Warranty Duration | 1 Year |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Chipset Manufacturer | Intel |
| Chipset Model | C252 |
| Controller Type | Serial ATA/600 |
| Controller Model | VROC |
| Product Type | Server |
| Manufacturer Part Number | P69102005 |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant MicroServer Gen10 Plus V2 Server |
| Product Line | ProLiant |
| Product Series | MicroServer Gen10 Plus v2 |
| Brand Name | HPE |
| Number of Total Expansion Bays | 4 |
| Number of 3.5" Bays | 4 |
| Total Number of Expansion Slots | 1 |
| Hot Swappable Bays | No |
| Number of LFF Bays | 4 |
| PCI Express Details | 1x standard (Low Profile) PCIe 4.0 |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 1 |
| Number of VGA Ports | 1 |
| Number of DisplayPorts | 1 |
| Remote Management Controller | HPE iLO 5 ASIC |
| Error Checking | ECC |
| Maximum Memory Supported | 64 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Standard Memory | 16 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Package Contents |
|
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Weight (Approximate) | 15.87 lb |
| Form Factor | Ultra Micro Tower |
| Height | 4.7" |
| Width | 9.7" |
| Depth | 9.7" |
| Plug/Connector Type | C5 |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Redundant Power Supply | No |
| Maximum Power Supply Wattage | 180 W |
| Processor Type | Pentium Gold |
| Processor Model | G6405 |
| Processor Core | Dual-core (2 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Cache | 4 MB |
| Processor Speed | 4.10 GHz |
| Processor Type | Pentium Gold |
| Processor Model | G6405 |
| Processor Core | Dual-core (2 Core) |
| Chipset Manufacturer | Intel |
| Chipset Model | C252 |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Additional Warranty Information | Server warranty includes 1-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response. |
