The Aruba CX 8100 Switch Series offers a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT era. These switches serve the needs of the next-generation core and aggregation layer of campuses, as well as virtual and highly dynamic data center environments. They provide up to 1.76 Tbps of capacity, with line-rate Gigabit Ethernet interfaces including support for Smart Rate (1/2.5/5 Gbps), 10Gbps, 25Gbps, 40Gbps, and 100Gbps.
The CX 8100 series includes industry-leading line rate ports with 1/10GbE (SFP/SFP+) and 40/100GbE (QSFP+/QSFP28) connectivity in a compact 1U form factor. 4x10Gbps and 4x25Gbps break out from 40/100G ports offer advanced flexibility in connectivity and aggregation.
These switches deliver a fantastic investment for customers requiring 1GbE/10GbEwith a mix of fiber and copper ports, and 40/100GbE uplink ports.
PRODUCT DIFFERENTIATORS
The Aruba CX 8100 switch series is based on ArubaOS-CX, a modern, database-driven operating system that automates and simplifies many critical and complex tasks. The enhanced capabilities of ArubaOS-CX provide a unique set of differentiators for campus and data center switching.
Modular Architecture with native cloud-native ArubaOS-CX
AOS-CX operating system features are organized into Aruba CX Foundation and Aruba CX Advanced software licenses. Every Aruba CX switch includes an active, embedded Aruba CX Foundation license at no additional cost with the option to upgrade to an Aruba CX Advanced license.
The CX Foundation license has everything needed to deploy, connect, and troubleshoot an enterprise network, including:
- Aruba Network Analytics Engine (NAE)
- Dynamic Segmentation
- High Availability and Resiliency
- Quality of Service (QoS)
- Layer 2 Switching
- Layer 3 Services and Routing
- IP Multicast
- Network Security
- Support for Aruba NetEdit
The Aruba CX Advanced license includes Aruba CX Edge Insights, offering flow capture from layer 4 to layer 7.
For more information on the CX Advanced License, read the Aruba CX Switch License Ordering Guide
Aruba Central, Cloud-based network management
Flexible cloud-based or on-premises management for unified network operations of wired, WLAN, SD-WAN, and public cloud infrastructure. Designed to simplify day zero through day two operations with streamlined workflows. Switch management capabilities include configuration, onboarding, monitoring, troubleshooting, and reporting.
An Aruba Central Advanced license expands these capabilities with premium security and AIOps, including the Aruba Central NetConductor Fabric Wizard and Policy Manager to enable dynamic segmentation and distributed enforcement at a global scale.
The Aruba Central Advanced license now comes with all Aruba CX Advanced features so there is no need to purchase a CX Advanced license. This streamlines operational efficiency, reducing the need for IT teams to keep track of multiple licenses, active terms, and renewal dates. For more information on Aruba Central licensing, see the Aruba Central SaaS Subscription Ordering Guide.
Key Features
- Supports layer 3 switching for enhanced performance and usability
- Surface Mount form factor for added reliability and dependability
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- Cascade to other network devices through the uplink port to expand your local area network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 40 ports
- Effectively reduces downtime with improved network performance
- Comes in black color for a sophisticated and dazzling look
Dimensions
| Height | 6 inches |
|---|---|
| Width | 22 inches |
| Length | 27.15 inches |
| Weight | 26.9 pounds |
| Product Type | Ethernet Switch |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Form Factor | Rack-mountable |
| Form Factor | Surface Mount |
| Form Factor | Compact |
| Form Factor | Cabinet Mount |
| Power Consumption | 500 W |
| Brand Name | HPE |
| Expansion Slot Type | QSFP28 |
| Expansion Slot Type | SFP+ |
| Expansion Slot Type | SFP |
| Expansion Slot Type | QSFP+ |
| Manageable | Yes |
| Ethernet Technology | 10 Gigabit Ethernet |
| Ethernet Technology | 100 Gigabit Ethernet |
| Product Family | CX 8100 |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 40 |
| Total Number of Expansion Slots | 12.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | R9W92AABA |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Model | 40XT8XF4C |
| Product Name | CX 8100 40XT8XF4C Ethernet Switch |
| Product Series | CX 8100 |
| Brand Name | HPE |
| Expansion Slot Type | SFP+ |
| Expansion Slot Type | SFP |
| Expansion Slot Type | QSFP28 |
| Expansion Slot Type | QSFP+ |
| Number of SFP+ Slots | 8 |
| Total Number of Expansion Slots | 12.0 |
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 40 |
| Port/Expansion Slot Details | 40 x 10 Gigabit Ethernet Network |
| Port/Expansion Slot Details | 8 x 10 Gigabit Ethernet Expansion Slot |
| Port/Expansion Slot Details | 4 x 100 Gigabit Ethernet Expansion Slot |
| Manageable | Yes |
| Network Technology | 100GBase-X |
| Network Technology | 10GBase-T |
| Network Technology | 10GBase-X |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Layer Supported | 3 |
| Weight (Approximate) | 18.89 lb |
| Height | 1.7" |
| Width | 17.4" |
| Depth | 16" |
| Compatible Rack Unit | 1U |
| Product Color | Black |
| Color Family | Black |
| Number of Power Supplies Supported | 2 |
