Product Overview
The Juniper EX3400-24T-TAA Managed Gigabit Ethernet Switch provides a high-performance, reliable, and scalable enterprise-quality performance in a small 1U rack mount. This Layer 2/3 switch is designed to support medium to large-sized business networks with high-speed connectivity, high security, and network management.
The EX3400-24T-TAA is powered with Juniper Junos OS, which has robust network control, automation, and easy administration through Juniper Virtual Chassis technology, which enables the connection of up to ten switches to be linked and operated as one logical device.
Switching 24 gigabit (10/100/1000Base-T) supports transmission of data with flawless flow to desktops, servers, and access points. Its dual redundant power supply, hot-swap fans, and advanced Layer 3 routing can be used to guarantee the best uptime and flexibility to mission-critical networked environments.
The EX3400-24T-TAA is compliant and can be deployed into government-compliant applications, and therefore, the device is ideal in federal and public applications due to the TAA (Trade Agreements Act) standards. It is also energy efficient, which minimizes the operational costs and does not compromise the network performance.
Key Features
-
High-Performance: Provides wire-speed Gigabit connectivity on 24 ports with high workload requirements.
-
Advanced Layer 2/3- Switching: The advanced switching offers VLANs, routing protocols, and multicast capabilities to the complex topology features of the network.
-
Virtual Chassis Technology: Archive 10 switches to manage and scale simply.
-
Junos OS Powered: Delivers trusted and efficient performance, automation, and safety with an integrated network operating system.
-
TAA-Compliant Design: Government and controlled industry approved.
-
Resilient Architecture: Provides redundancy in power supply and fans to continue operating the network.
-
Energy Saving: Highly optimized to consume low amounts of energy and low operation costs.
-
Extended Security: MACsec, DHCP snooping, and dynamic ARP inspection are features that provide a better level of security.
-
1U Rackmount Form Factor: Small size to fit data centers and enterprise wiring closets.
-
Low Noise: Unobtrusive performance at the office and branch level.
Technical Specifications
|
Feature |
Specification |
|
Brand |
Juniper Networks |
|
Model |
EX3400-24T-TAA |
|
Series |
EX3400 |
|
Form Factor |
1U Rackmount |
|
Management Type |
Managed |
|
Switching Layer |
Layer 2 / Layer 3 |
|
Total Ports |
24 |
|
Port Type |
10/100/1000Base-T (RJ-45) |
|
Uplink Ports |
4 × 10GbE SFP+ |
|
Switching Capacity |
336 Gbps |
|
Forwarding Rate |
130 Mpps |
|
Virtual Chassis Support |
Up to 10 switches |
|
MAC Address Table Size |
32,000 entries |
|
Jumbo Frame Support |
Up to 9216 bytes |
|
VLAN Support |
4094 VLANs |
|
Routing Protocols |
RIP, OSPF, BGP, IGMP, VRRP |
|
Security Features |
MACsec, 802.1X, DHCP Snooping, Dynamic ARP Inspection |
|
Power Supply |
Internal, Redundant (Optional) |
|
Cooling |
Front-to-back airflow with hot-swappable fans |
|
Mounting |
19-inch rackmount |
|
Color |
Gray |
|
Compliance |
TAA Compliant |
|
Operating Temperature |
32°F – 113°F (0°C – 45°C) |
|
Dimensions (H × W × D) |
1.75 × 17.4 × 10.7 in (44 × 442 × 272 mm) |
|
Weight |
9.9 lb (4.5 kg) |
|
Operating System |
Junos OS |
|
Warranty |
Limited Lifetime Warranty |
