Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle, monitor site electrical conditions and remotely monitor output power consumption. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1, SNMPv2, SNMPv3, telnet, SSH, FTP, DHCP, BOOTP and NTP. Individually switched outlets can be controlled in real-time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent inrush-related overloads as network equipment is first energized. Unused PDU outlets can be electronically locked off to prevent the connection of unauthorized hardware. PDU output current consumption in amps is continuously displayed locally via visual meter and remotely via web/network interface to warn of potential overloads before critical IT mains or branch breakers trip.
More from the Manufacturer
Key Features
- Switched 20A 120V PDU, 1U horizontal rackmount format
- Reports voltage, frequency & load level via ethernet interface
- Visual current meter, Reversible housing
- NEMA L5-20P input with 5-20P plug adapter, 12 ft. / 3.6m line cord
- 16 NEMA 5-15/20R switched outlets with cord retention brackets
- Temperature, humidity and contact closure monitoring options
- TAA Compliant
Dimensions
| Height | 5.05 inches |
|---|---|
| Width | 21 inches |
| Length | 23 inches |
| Weight | 18 pounds |
| Product Type | PDU |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Mount Type | Wall-mountable |
| Mount Type | Rack-mountable |
| Rack Height | 1U |
| Brand Name | Eaton |
| Plug/Connector Type | NEMA L5-20P |
| Receptacle Type | NEMA 5-15/20R |
| Product Family | Switched Metered |
| TAA Compliant | Yes |
| PDU Type | Switched |
| Mounting Orientation | Vertical |
| Receptacle Detail | 16 x NEMA 5-15/20R |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | PDU |
| Manufacturer Part Number | PDUMH20NET |
| Manufacturer Website Address | http://www.eaton.com |
| Manufacturer | Eaton Corporation |
| Product Model | PDUMH20NET |
| Product Name | Switched Metered PDUMH20NET 16-Outlets PDU |
| Product Series | Switched Metered |
| Brand Name | Eaton |
| Management | Protocols:
|
| Package Contents |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Weight (Approximate) | 12.50 lb |
| Rack Height | 1U |
| Height | 1.8" |
| Width | 17.5" |
| Depth | 15.5" |
| Mounting Orientation | Vertical |
| Plug/Connector Type | NEMA L5-20P |
| Receptacle Type | NEMA 5-15/20R |
| Receptacle Detail | 16 x NEMA 5-15/20R |
