AMD EPYC™ 9004 single-processor 1U server that supports up to 24 DIMM, 16 NVMe, three PCIe® 5.0 slots, two M.2, OCP 3.0, two single-slot GPUs, and ASUS ASMB11-iKVM
KEY FEATURES
- Powerful performance:Powered by AMD EPYC 9004 processors with 96 Zen 4 cores, 12-channel, up to 4800 MHz DDR5 and support for a maximum TDP of up to 400 watts
- Scale-up storage and expansion design: Up to 12 all-flash NVMe drives on the front panel, 4 NVMe in middle bay, and 3 PCIe 5.0 slots for higher bandwidth and system upgrade
- Flexible networking module design:On-board LAN module, and OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity
- Advanced air cooling solution: Features enhanced volume air cooling (EVAC) heatsink for processors with higher TDP
- Enhanced IT-infrastructure management:ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT management software and hardware-level Root-of-Trust solution
- Read for AI and HPC workloads:Up to two single-slot GPUs.
PCIe 5.0 Ready | Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.
AMD EPYC™ 9004 Series Processors
The 9004 Series EPYC CPUs amplifies the AMD history of x86 architecture innovations and record-breaking performance with next generation 5nm technology as well as introducing support for high performant DDR5 DIMMs and fast PCIe® Gen 5 I/O. EPYC 9004 CPUs support 12 memory channels with 2 DIMMs/channel capability, delivering the resources needed for memory hungry AI, ML, HPC, and large in-memory computations.
World Records Leadership
ASUS holds the most amount of records in dual-socket (2P) and single-socket (1P) on SPEC CPU 2017 benchmark and dominate the computing performance. These top performance results provide a useful insight into compute-intensive workloads on different computer systems, enabling our customers to reduce complexity, tackle challenging workloads and accelerate system validations.
ASUS servers feature Performance Boost technology to achieve the best server performance and agility by tuning servers to match the requirements of workloads, letting you gain greater control of your server environment. This technology improves workload throughput by maximizing processor frequency and boost power, ideal for timesensitive applications such as financial services or data center operations.
Core Optimizer
Maximizes the processor frequency in multi-core operations, avoiding frequency shifting for reduced latency.
More from the Manufacturer
Key Features
- Perform computational tasks effectively accrediting the EPYC processor
- Serial ATA interface provides quick data transfer and greater throughput
- DDR5 SDRAM slot for convenient installation of memory
- Gigabit Ethernet is very resourceful when a large number of file transfers are required, such as when performing backups over a network
- Can connect up to 2 USB peripherals
Dimensions
| Height | 7.5 inches |
|---|---|
| Width | 23.5 inches |
| Length | 45 inches |
| Weight | 49.1 pounds |
| Product Type | Barebone System |
| Maximum Memory Supported | 6 TB |
| Chipset | AMD |
| Form Factor | Rack-mountable |
| Processor Supported | EPYC |
| Controller Type | Serial ATA |
| Processor Socket | Socket SP5 LGA-6096 |
| Rack Height | 1U |
| Brand Name | Asus |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Graphics Controller Model | AST2600 |
| Number of Processors Supported | 1 |
| Ethernet Technology | Gigabit Ethernet |
| Number of PCI Express x16 Slots | 4 |
| Maximum Power Supply Wattage | 1600 W |
| Product Family | RS500A-E12-RS12U |
| Total Number of USB Ports | 2 |
| Total Number of Expansion Slots | 4 |
| Total Number of Memory Slots | 24 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Chipset Manufacturer | AMD |
| Controller Type | Serial ATA |
| Product Type | Barebone System |
| Manufacturer Part Number | RS500A-E12-RS12U-12W12B |
| Manufacturer Website Address | http://usa.asus.com |
| Manufacturer | ASUS Computer International |
| Product Model | RS500A-E12-RS12U-12W12B |
| Product Name | RS500A-E12-RS12U-12W12B Barebone System |
| Product Series | RS500A-E12-RS12U |
| Brand Name | Asus |
| Number of Total Expansion Bays | 12 |
| Number of PCI Express x16 Slots | 4 |
| Total Number of Expansion Slots | 4 |
| Total Number of USB Ports | 2 |
| Number of VGA Ports | 1 |
| Number of USB 3.2 Gen 1 Ports | 2 |
| Maximum Memory Supported | 6 TB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Total Number of Memory Slots | 24 |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Weight (Approximate) | 31.22 lb |
| Form Factor | Rack-mountable |
| Rack Height | 1U |
| Height | 1.7" |
| Width | 17.7" |
| Depth | 33.2" |
| Number of Power Supplies Installed | 2 |
| Maximum Power Supply Wattage | 1600 W |
| Processor Supported | EPYC |
| Processor Socket | Socket SP5 LGA-6096 |
| Number of Processors Supported | 1 |
| Processor Supported | EPYC |
| Processor Socket | Socket SP5 LGA-6096 |
| Chipset Manufacturer | AMD |
| Number of Processors Supported | 1 |
