Perle's advanced S-1110DPP-S1SC10U Gigabit PoE+ Media Converter seamlessly bridges copper and fiber optic networks, delivering Power over Ethernet (PoE) to compliant devices like IP cameras, VoIP phones, and wireless access points. Classified as Power Sourcing Equipment (PSE), this converter injects power directly through standard UTP Ethernet cables, eliminating the need for separate power adapters for connected Powered Devices (PDs). It supports the IEEE 802.3at PoE+ standard, providing up to 30W of power per port, enabling the deployment of higher-power devices. This versatile converter offers an economical solution to extend existing network infrastructure over fiber optic cabling while simultaneously functioning as a PoE injector. Its dual 10/100/1000BASE-T copper ports connect to standard Ethernet devices, while the single 1000BASE-BXU fiber port, featuring an SC connector and a reach of 10 kilometers, facilitates long-distance communication in environments demanding high bandwidth and reliability.
Dimensions
| Height | 2.75 inches |
|---|---|
| Width | 7.9 inches |
| Length | 11.8 inches |
| Weight | 3.1 pounds |
| Product Type | Transceiver/Media Converter |
| Maximum Distance Supported | 10 km |
| Form Factor | Rack-mountable |
| Form Factor | Rail-mountable |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 1000Base-BX-U |
| Brand Name | Perle |
| Number of PoE+ (RJ-45) Ports | 2 |
| Number of SC Ports | 2 |
| Total Number of Ports | 4 |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | 05083144 |
| Manufacturer Website Address | http://www.perle.com |
| Manufacturer | Perle Systems, Inc |
| Product Model | S-1110DPP-S1SC10U |
| Product Name | S-1110DPP-S1SC10U Media Converter |
| Brand Name | Perle |
| Number of PoE+ (RJ-45) Ports | 2 |
| Number of SC Ports | 2 |
| Total Number of Ports | 4 |
| Maximum Distance Supported | 10 km |
| Package Contents |
|
| Country of Origin | Canada |
| Environmentally Friendly | Yes |
| Network Technology | 10/100/1000Base-T |
| Network Technology | 1000Base-BX-U |
| Height | 1" |
| Width | 3.7" |
| Depth | 5.9" |
