Product Overview
Samsung QM43B-T is an interactive all-in-one 43-inch UHD touch screen that is targeted at the business, retail, and public settings where it is necessary to have clarity, reliability, and engagement. With native 4K resolution, capacitive touch, built-in media player (Tizen OS), and a rugged and dust-resistant design, it allows you to showcase bright displays and interact without an external PC. It works well in signage, info-kiosk, interactive presentation, and hybrid meeting rooms.
Key Features and Benefits
-
Entertaining, Sharp Visuals: Provides native 4K UHD (3840x2160) resolution to a VA panel, thus, you will have sharp detail and high pixel density to enable text, pictures, and video to appear crisp even when they are up close.
-
Solid Augmentation Performance: Capacitive touch input and responsive touch interaction, combined with non-glare and haze-treated glass to minimize reflections and increase usage in high-light or front-of-store areas.
-
In one Design with Tizen and MagicINFO: Inbuilt Tizen OS (v6.5) is used to drive internal processing, and MagicINFO S10 provides the opportunity to schedule, update, and manage content without the use of additional hardware.
-
Strong and resistant to dust: IP5X dust-resistant and conformal coating ensures the display withstands dusty or high-traffic environments, and center IR, temperature sensors, and symmetrical design can ensure stability in the long run.
-
Universal Connectivity: 5 HDMI ports, DisplayPort, USB, touch output (USB), network (Ethernet / WiFi / Bluetooth), RS-232 control, and audio output allow a wide range of signal sources to be deployed.
-
Full Daylight — 24/7 Unlimited Use: The display is rated to operate 24/7, in landscape or portrait mode; it is designed to be installed in places where the display has to be continuously in use.
Technical Specifications
|
Feature |
Specification |
|
Model |
Samsung QM43B-T (QMB-T Series) |
|
Display Size |
43″ diagonal (≈ 42.5″ viewable) |
|
Panel Type |
VA LCD with LED backlight |
|
Native Resolution |
3840 × 2160 (4K UHD) |
|
Pixel Pitch |
≈ 0.2451 × 0.2451 mm |
|
Brightness (Typical) |
500 nits (without touch glass) / ~ 400 nits (with touch glass) |
|
Contrast Ratio (Static) |
~ 4000 1 |
|
Viewing Angle (H / V) |
178° / 178° |
|
Color Gamut |
~ 92% DCI-P3 (CIE 1976) |
|
Haze / Glare Treatment |
|
|
Touch Technology |
Capacitive touch; includes USB touch out (PC / screen) |
|
Inputs / Ports |
3× HDMI 2.0, 1× DisplayPort 1.2, 2× USB-A 2.0, RJ-45 Ethernet, WiFi, Bluetooth, RS-232 in/out |
|
Audio Output |
2× 10 W speakers; stereo mini-jack output |
|
Power Supply / Consumption |
AC 100-240 V, 50/60 Hz; Typical ~ 90 W; Max ~ 110 W |
|
Dimensions (Set) |
≈ 986.2 × 584.4 × 56.7 mm |
|
Weight (Set) |
~ 14.5 kg |
|
Mounting (VESA) |
200 × 200 mm |
|
Operating Conditions |
0-40 °C; 10-80% humidity (non-condensing) |
|
Duty Cycle |
24 hours / 7 days continuous conversation |
|
Special Features |
Built-in Tizen OS 6.5; MagicINFO S10; center IR; auto source switching & recovery; IP5X dust resistance; symmetric bezel; supports both orientations; web-engine upgradable; temperature sensor; remote calibration, etc. |
Product Information
The Samsung QM43B-T is a blend of a professional quality touch screen and strong signage capabilities, and construction capable of sustaining its application in a business environment. The VA panel has a good contrast, large viewing angles, and at approximately 500 nits of brightness (before the addition of touch glass), the display is visible even in the bright ambient light. The haze and non-glare treatment assists in eliminating reflections to enhance the user experience in frontier or semi-lit areas.
Touch is capacitive, providing responsive input, and the display has a USB touch out to connect with PCs. The inbuilt Tizen operating system and MagicINFO S10 in it enable you to manage the scheduling of content, remote updates, source recovery, and calibration, among others, without overdepending on other tools. The design is designed with durability attributes such as dust protection (IP5X), conformal coating, and a center IR sensor, among others, to be resistant to dusty, often touched, or open-access areas.
Connections are thorough, and it has several HDMI, DisplayPort, USB, etc., connectors, as well as audio and control connections (RS232, audio jack). The power consumption is small for a 43-inch UHD touch screen, but in case of installation where one has to have a large number of monitors or whose work duration is significant, one must consider giving adequate electrical and cooling backup.
To conclude, in applications such as interactive retail signs, kiosks, meeting room whiteboard-style displays, or touch-enabled signage, the QM43B-T has a good combination of clarity, durability, and features, particularly when it is required to be all-in-one with no external media players.
