Key Features
- Perfect for applications that require direct association with a workstation or a notebook
- LED aimer is a perfect choice for patient-facing applications
- Reads all 1D barcodes with ease so you can accomplish all your tasks more efficiently
- Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
Dimensions
| Height | 3.65 inches |
|---|---|
| Width | 3.95 inches |
| Length | 7.7 inches |
| Weight | 1.19 pounds |
| Host Interface | USB |
| Product Type | Barcode Scanner Kit |
| Limited Warranty | 1 Year |
| Connectivity Technology | Cable |
| Form Factor | Handheld |
| Brand Name | HP |
| Scanning Distance | 9.80" |
| Light Source | LED |
| Scan Pattern | Linear |
| Image Sensor Type | Imager |
| Product Family | Engage One Prime |
| Stand Included | Yes |
| Product Color | Black |
| Color Family | Black |
| Ingress Protection (IP) Rating | IP42 |
| Cable Type Included | USB |
| Scanning Capability | 1D |
| Scanning Capability | 2D |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Product Type | Barcode Scanner Kit |
| Manufacturer Part Number | 638L9AT |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Engage One Prime Barcode Scanner Kit |
| Product Line | Engage One Prime |
| Brand Name | HP |
| Host Interface | USB |
| Package Contents |
|
| Compatibility |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Weight (Approximate) | 4.06 oz |
| Form Factor | Handheld |
| Height | 2.7" |
| Width | 5.7" |
| Depth | 4" |
| Product Color | Black |
| Color Family | Black |
| Limited Warranty | 1 Year |
| Barcode Symbology Supported | 1D:
2D:
|
| Scanning Distance | 9.80" |
| Light Source | LED |
| Depth of Field |
|
| Scan Pattern | Linear |
| Image Sensor Type | Imager |
| Stand Included | Yes |
| Cable Type Included | USB |
| Scanning Capability | 2D |
| Scanning Capability | 1D |
| Reading Angle (Skew) | 40° |
| Reading Angle (Pitch) | 45° |
| Reading Angle (Roll) | 360° |
| Minimum Print Contrast | 25% |
| Minimum Element Resolution (Code 39) | 5 mil |
| Maximum Element Resolution (Code 39) | 10 mil |
| Minimum Element Resolution (DataMatrix) | 10 mil |
| Maximum Element Resolution (DataMatrix) | 15 mil |
| Minimum Element Resolution (PDF417) | 6.7 mil |
| Maximum Element Resolution (PDF417) | 10 mil |
