Full size Z tower power at half the size
Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow-from 3D design to real time ray tracing-now and in the future.
Full height, full length performance
Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
ISV Certified
Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.
Configurable for today. Expandable for tomorrow.
Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
Featuring | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Intel® Core™ i7 processor
Run several CPU-heavy programs simultaneously without sacrificing performance with an Intel® Core™ i7 processor.
Security is your top priority
The HP Wolf Pro Security Edition provides precongured enterprise-level PC protection for small and medium sized businesses.
Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location.
Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs.
Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7.
Key Features
- ISV Certified
- Configurable for today. Expandable for tomorrow.
- Full height, full length performance
Dimensions
| Height | 7.8 inches |
|---|---|
| Width | 19.4 inches |
| Length | 20.1 inches |
| Weight | 17 pounds |
| Product Type | Workstation |
| Standard Memory | 16 GB |
| Operating System | Windows 11 Pro |
| Chipset | Intel W680 |
| Form Factor | Small Form Factor |
| Processor Speed | 2.10 GHz |
| Processor Type | Core i7 |
| RAID Levels | 0, 1 |
| Controller Type | NVMe |
| Controller Type | Serial ATA/600 |
| Brand Name | HP |
| Memory Technology | DDR5 SDRAM |
| Processor Model | i7-14700 |
| Graphics Controller Model | RTX A400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Solid State Drive Interface | PCI Express NVMe |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Maximum Power Supply Wattage | 450 W |
| DisplayPort | Yes |
| Product Family | Z2 G9 |
| Total Solid State Drive Capacity | 512 GB |
| Operating System Platform | Windows |
| Keyboard Localization | English |
| Operating System Language | English |
| Processor Generation | 14th Gen |
| Energy Star | Yes |
| USB Type-C | Yes |
| Limited Warranty Duration | 1 Year |
| Product Color | Black |
| Color Family | Black |
| TCO Certified | Yes |
| Total Number of Memory Slots | 4 |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| RAID Levels | 0, 1 |
| Controller Type | NVMe |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Product Type | Workstation |
| Manufacturer Part Number | B29Y6UT#ABA |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Z2 Small Form Factor G9 Workstation |
| Product Series | Z2 G9 |
| Brand Name | HP |
| Keyboard Localization | English |
| DisplayPort | Yes |
| Total Number of USB Ports | 12 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge |
| Maximum Memory | 128 GB |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 1 x 16GB |
| Total Number of Memory Slots | 4 |
| Package Contents |
|
| Energy Star | Yes |
| TCO Certified | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Operating System | Windows 11 Pro |
| Operating System Platform | Windows |
| Operating System Language | English |
| Weight (Approximate) | 11.02 lb |
| Form Factor | Small Form Factor |
| Height | 3.9" |
| Width | 15.1" |
| Depth | 12.1" |
| Product Color | Black |
| Color Family | Black |
| Maximum Power Supply Wattage | 450 W |
| Error Checking | Non-ECC |
| Signal Processing | Unbuffered |
| Processor Type | Core i7 |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Generation | 14th Gen |
| Processor Speed | 2.10 GHz |
| Processor Type | Core i7 |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Generation | 14th Gen |
| Operating System | Windows 11 Pro |
| Operating System Platform | Windows |
| Operating System Language | English |
| Drive Type | SSD |
| Solid State Drive Interface | PCI Express NVMe |
| Total Solid State Drive Capacity | 512 GB |
