The DGS-1210 Series switches support 8, 16, 24, or 48 10/100/1000BASE-T ports. In addition, each switch supports 2 or 4 Gigabit SFP ports for optical connections using multimode or singlemode SFP transceivers.
PoE Support
Several models in the DGS-1210 series family support Power-over-Ethernet capabilities, simplifying deployments with IP cameras, VoIP phones, wireless access points, and other powered devices. These models include the DGS-1210-10P, DGS-1210-28P and DGS-1210-52MP. Using the switch's management interface, an administrator can control various PoE functions, such as remotely rebooting cameras or access points, from anywhere on the network, including over the Internet. The switches also support time-based PoE - an option that allows administrators to set a time window that determines when each port's PoE power is turned on and off.
Energy Saving
The DGS-1210 Series Switches are capable of conserving power without sacrificing operational performance or functionality by using D-Link Green 3.0 technology. Using the Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low. For environments not fully supporting the standard, these switches offer advanced powersaving settings including port shutoff and standby, LED shutoff, and system hibernation based on custom time profiles. The time profiles can also be applied to the PoE switches so that unnecessary power consumption can be saved during off hours. The switches can also detect the length of connected cables to automatically reduce power usage on shorter cable connections.
More from the Manufacturer
Key Features
- Can work as layer 3 routing for scalable network design
- Rack mounting enables you to organize wires & secure cables for professional installation
- Managed switch provides a reliable foundation for your network
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Conveniently lets you connect two standard Ethernet ports to ensure maximum efficiency
- Electrical power is transmitted along with data in a single cableto devices such as Access Points, IP cameras or IP phones
- Twisted Pair media support for efficient and reliable connectivity
- Quickly and easily set up a wired network with 8 networking ports
- Ethernet Switch ensures productivity by providing an efficient, hassle-free connection
- Comes in black color for better adaption to the space
Dimensions
| Height | 2.9 inches |
|---|---|
| Width | 11.4 inches |
| Length | 13 inches |
| Weight | 4.7 pounds |
| Product Type | Ethernet Switch |
| Power Source | Power Supply |
| Layer Supported | 3 |
| Form Factor | Desktop |
| Form Factor | Rack-mountable |
| Brand Name | D-Link |
| Expansion Slot Type | SFP |
| Manageable | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Product Family | WebSmart DGS-1210 |
| Stack Port | No |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Total Number of Network Ports | 8 |
| PoE (RJ-45) Port | No |
| Total Number of Expansion Slots | 2.0 |
| Energy Star | Yes |
| Product Type | Ethernet Switch |
| Manufacturer Part Number | DGS-1210-10P |
| Manufacturer Website Address | http://www.dlink.com |
| Manufacturer | D-Link Systems, Inc |
| Product Model | DGS-1210-10 |
| Product Name | 10-Port Gigabit Web Smart Switch Including 2 Gigabit SFP Ports |
| Product Line | WebSmart |
| Product Series | DGS-1210 |
| Brand Name | D-Link |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Total Number of Expansion Slots | 2.0 |
| Token Ring Port | No |
| LRE Port | No |
| USB | No |
| Modular | No |
| Management Port | No |
| Uplink Port | Yes |
| Number of PoE (RJ-45) Ports | 8 |
| Stack Port | No |
| Bypass | No |
| Total Number of Network Ports | 8 |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet Network |
| Port/Expansion Slot Details | 2 x Gigabit Ethernet Expansion Slot |
| Management |
|
| Manageable | Yes |
| Network Technology | 1000Base-X |
| Network Technology | 10/100/1000Base-T |
| Twisted Pair Cable Standard | Category 5e |
| Media Type Supported | Optical Fiber |
| Media Type Supported | Twisted Pair |
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| Layer Supported | 3 |
| Weight (Approximate) | 3.39 lb |
| Height | 1.7" |
| Width | 11" |
| Depth | 5" |
| Compatible Rack Unit | 1U |
| Product Color | Black |
| Product Color | Gray |
| Color Family | Dual Color |
| PoE (RJ-45) Port | No |
| MTBF | 360844 Hour |
