The Ultrastar Serv24 SVR2U24 is a performance-optimized 2U storage server meticulously engineered to address the growing demand for increased data center performance in storage-intensive applications. As a validated building block for software-defined storage (SDS) deployments, it seamlessly integrates powerful Intel® Xeon® CPUs and cutting-edge NVMe™ SSDs within a single, high-density unit. This architecture ensures accelerated data delivery at the speed of flash, offering low latency and consistently high bandwidth, making it ideal for both standalone file server roles and scale-out SDS environments.
Dimensions
| Product Type | NAS Storage System |
| Standard Memory | 256 GB |
| Form Factor | Rack-mountable |
| Processor Speed | 2.30 GHz |
| Processor Type | Xeon Gold |
| Rack Height | 2U |
| Brand Name | HGST |
| Expansion Slot Type | PCI Express x16 |
| Expansion Slot Type | PCI Express x8 |
| Processor Manufacturer | Intel |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Bays | 24 |
| Number of Total Expansion Slots | 3 |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 1200 W |
| Product Family | Ultrastar Serv24 |
| Total Number of USB Ports | 2 |
| Total Solid State Drive Capacity Installed | 153.60 TB |
| Number of 2.5" Bays | 24 |
| Limited Warranty Duration | 5 Year |
| Product Type | NAS Storage System |
| Manufacturer Part Number | 1ES1015 |
| Manufacturer Website Address | http://www.wdc.com |
| Manufacturer | Western Digital Corporation |
| Product Name | Ultrastar Serv24 NAS Storage System |
| Product Line | Ultrastar Serv24 |
| Brand Name | HGST |
| Expansion Slot Type | PCI Express x8 |
| Expansion Slot Type | PCI Express x16 |
| Number of Total Expansion Bays | 24 |
| Number of 2.5" Bays | 24 |
| VGA | Yes |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Standard Memory | 256 GB |
| Ethernet Technology | 10 Gigabit Ethernet |
| Weight (Approximate) | 54.90 lb |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 17.6" |
| Depth | 29.9" |
| Operating Power Consumption | 1200 W |
| Maximum Power Supply Wattage | 1200 W |
| Processor Speed | 2.30 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 6140 |
| Processor Core | Octadeca-core (18 Core) |
| Processor Manufacturer | Intel |
| Total Solid State Drive Capacity Installed | 153.60 TB |
| Number of Solid State Drive Supported | 24 |
| Number of Solid State Drive Installed | 24 |
| Number of Boot Drives | 2 |
