The Ultrastar® Serv24 is a performance-optimized storage server specifically engineered for data center demands in storage-intensive applications. As a robust building block for Software-Defined Storage (SDS) deployments, it integrates powerful Intel® Xeon® CPUs with high-speed NVMe™ SSDs within a single unit. This tested and validated platform delivers exceptional performance for SDS stacks, accelerating data access and enabling the full potential of flash technology. Its flexible design, allowing for customization of chipset, core count, and CPU power, ensures it can be tailored to meet diverse workload and performance requirements. Whether utilized as a standalone file server or integrated into a scale-out architecture, the Ultrastar Serv24 is built to provide consistent, high bandwidth, and low latency, ensuring data is processed at the speed of flash.
Dimensions
| Product Type | NAS Storage System |
| Standard Memory | 256 GB |
| Form Factor | Rack-mountable |
| Processor Speed | 2.30 GHz |
| Processor Type | Xeon Gold |
| Controller Type | NVMe |
| Rack Height | 2U |
| Brand Name | HGST |
| Expansion Slot Type | PCI Express 3.0 x16 |
| Expansion Slot Type | PCI Express 3.0 x8 |
| Ethernet Technology | 10 Gigabit Ethernet |
| Number of Total Expansion Bays | 24 |
| Number of Total Expansion Slots | 3 |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 1200 W |
| Product Family | Ultrastar Serv24 |
| Total Number of USB Ports | 2 |
| Total Solid State Drive Capacity Supported | 184 TB |
| Total Solid State Drive Capacity Installed | 76.80 TB |
| Number of 2.5" Bays | 24 |
| Drive Interface | PCI Express |
| Limited Warranty Duration | 5 Year |
| Controller Type | NVMe |
| Product Type | NAS Storage System |
| Manufacturer Part Number | 1ES1027 |
| Manufacturer Website Address | http://www.wdc.com |
| Manufacturer | Western Digital Corporation |
| Product Model | SS2U24PUR-1023 |
| Product Name | Ultrastar Serv24 SS2U24PUR-1023 NAS Storage System |
| Product Line | Ultrastar Serv24 |
| Brand Name | HGST |
| Expansion Slot Type | PCI Express 3.0 x8 |
| Expansion Slot Type | PCI Express 3.0 x16 |
| Number of Total Expansion Bays | 24 |
| Number of 2.5" Bays | 24 |
| VGA | Yes |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Drive Interface | PCI Express |
| Standard Memory | 256 GB |
| Memory Technology | DDR4 SDRAM |
| Ethernet Technology | 10 Gigabit Ethernet |
| Weight (Approximate) | 54.90 lb |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 17.6" |
| Depth | 29.9" |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| Maximum Power Supply Wattage | 1200 W |
| Processor Speed | 2.30 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 6140 |
| Processor Core | Octadeca-core (18 Core) |
| Total Solid State Drive Capacity Supported | 184 TB |
| Total Solid State Drive Capacity Installed | 76.80 TB |
| Number of Solid State Drive Supported | 24 |
| Number of Solid State Drive Installed | 24 |
| Number of Boot Drives | 2 |
