The UCS C240 SD M5 SFF server is a two-socket C-Series 2U chassis designed to operate both in standalone
and UCS environments. It serves the edge computing market that uses standard x86 based 19" rack servers.
The UCS C240 SD M5 SFF server is a derivative of the Cisco UCS 240 M5 server.
The following list summarizes the C240 SD M5 server features that are identical to the C240 M5 features:
- 2U form factor
- 2nd Gen Intel® Xeon® Processor Scalable Family (maximum 2 CPUs)
- 24 DIMM slots for 2933-MHz DIMMs with DIMM sizes up to 128 GB and 2666-MHz PMem with capacity points up to 512 GB
- Maximum memory size is 7.6 TB (using 12 x 128 GB DDR4 DIMMs and 12 x 512 GB PMem)
- Six PCIe slots
- Cisco 12G Modular SAS HBA
- Cisco 12G Modular RAID controller
Key Features
- Perform computational tasks effectively accrediting the Xeon Platinum processor
- 12Gb/s SAS interface for high speed and reliability
- DDR4 SDRAM compatible slot - Installs memory that reduces processor's idle time and enhances computer's performance
- Optimize business network's performance with 10 Gigabit Ethernet connectivity
- Can connect up to 2 USB peripherals
Dimensions
| Product Type | Barebone System |
| Maximum Memory Supported | 7.60 TB |
| Limited Warranty | 3 Year |
| Chipset | Intel C621 |
| Form Factor | Rack-mountable |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Silver |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Controller Type | 12Gb/s SAS |
| Rack Height | 2U |
| Brand Name | Cisco |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2933/PC4-23466 |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 8 MB |
| Number of Processors Supported | 2 |
| Ethernet Technology | Gigabit Ethernet |
| Ethernet Technology | 10 Gigabit Ethernet |
| Product Family | C240 SD M5 |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Total Number of Expansion Slots | 6 |
| Total Number of Memory Slots | 24 |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| Product Type | Barebone System |
| Manufacturer Part Number | UCSCC240M5SD |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS C240 SD M5 Barebone System |
| Product Series | C240 SD M5 |
| Brand Name | Cisco |
| Total Number of Expansion Slots | 6 |
| Number of Network (RJ-45) Ports | 2 |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Number of VGA Ports | 1 |
| Maximum Memory | 7.60 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Card Supported | SD |
| Memory Card Supported | microSD |
| Memory Standard | DDR4-2933/PC4-23466 |
| Total Number of Memory Slots | 24 |
| Weight (Approximate) | 40.57 lb |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 3.4" |
| Width | 19" |
| Depth | 22.9" |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Silver |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Gold |
| 64-bit Processing | Yes |
| Number of Processors Supported | 2 |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Silver |
| 64-bit Processing | Yes |
| Chipset Manufacturer | Intel |
| Chipset Model | C621 |
| Number of Processors Supported | 2 |
| Additional Warranty Information |
|
| Limited Warranty | 3 Year |
