The Cisco UCS X-Series Modular System simplifies your data center, adapting to the unpredictable needs of modern applications while also providing for traditional scale-out and enterprise workloads. It reduces the number of server types to maintain, helping to improve operational efficiency and agility as it helps reduce complexity. Powered by the Cisco Intersight™ cloud operations platform, it shifts your thinking from administrative details to business outcomes with hybrid cloud infrastructure that is assembled from the cloud, shaped to your workloads, and continuously optimized.
The Cisco UCS X210c M7 Compute Node is the computing device to integrate into the Cisco UCS X-Series Modular System. Up to eight compute nodes can reside in the 7-Rack-Unit (7RU) Cisco UCS X9508 Chassis, offering one of the highest densities of compute, IO, and storage per rack unit in the industry.
Key Features
- Compatible Xeon Bronze processor lets you perform all your computational tasks at a swift pace
- With Serial ATA interface get superb reliability and high-speed data transfer
- Optimize workflows by sharing the resources of the workstation using Ethernet connectivity
- The DDR5 SDRAM memory technology efficiently move data across electric components and provide smooth PC performance
Dimensions
| Product Type | Barebone System |
| Maximum Memory Supported | 8 TB |
| Chipset | Intel C741 |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Silver |
| Controller Type | Serial ATA |
| Controller Type | Serial Attached SCSI (SAS) |
| Controller Type | NVMe |
| Brand Name | Cisco |
| Operating System Supported | Windows Server 2022 Standard |
| Operating System Supported | Windows Server 2019 Standard |
| Operating System Supported | Windows Server 2022 Datacenter |
| Operating System Supported | Windows Server 2019 Datacenter |
| Operating System Supported | SuSE Linux Enterprise Server |
| Operating System Supported | Red Hat Enterprise Linux |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-5600/PC5-44800 |
| Graphics Controller Model | G200e |
| Graphics Memory Capacity | 16 MB |
| Number of Processors Supported | 2 |
| Ethernet Technology | Ethernet |
| Product Family | X210c M7 |
| Total Number of Memory Slots | 32 |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Controller Type | Serial Attached SCSI (SAS) |
| Controller Type | Serial ATA |
| Controller Type | NVMe |
| RAID Supported | Yes |
| Product Type | Barebone System |
| Manufacturer Part Number | UCSX-210C-M7-U |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Name | UCS X210c M7 Barebone System |
| Product Series | X210c M7 |
| Brand Name | Cisco |
| Number of Total Expansion Bays | 6 |
| Number of 2.5" Bays | 6 |
| Number of M.2 Interfaces | 2 |
| Maximum Memory Supported | 8 TB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-5600/PC5-44800 |
| Intel Optane Memory Ready | Yes |
| Total Number of Memory Slots | 32 |
| Weight (Approximate) | 25.11 lb |
| Height | 1.8" |
| Width | 11.3" |
| Depth | 23.7" |
| Processor Supported | Xeon Silver |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Gold |
| Processor Supported | Xeon Bronze |
| 64-bit Processing | Yes |
| Number of Processors Supported | 2 |
| Processor Supported | Xeon Bronze |
| Processor Supported | Xeon Silver |
| Processor Supported | Xeon Platinum |
| Processor Supported | Xeon Gold |
| 64-bit Processing | Yes |
| Chipset Manufacturer | Intel |
| Chipset Model | C741 |
| Number of Processors Supported | 2 |
