Product Overview
ViewSonic IFP8650-E1 is a 4K UHD interactive smart board in 86-inch designed to fit educational centers, meeting rooms and collaborative spaces in corporate organizations. It provides a big, high-resolution teaching, brainstorming, and presenting canvas as well as responsive touch, plentiful connectivity, and remote manageability. It includes integrated features like an included wall mount and a wireless adapter, making it a near plug-and-play solution to applications where a large screen environment requires interactive capabilities without complex installation.
Key Features and Benefits
Extended Visual Clarity: The 4K Ultra HD native (3840×2160) resolution on the huge 86-inch screen has sharp details in terms of text, pictures, and video, which makes material easily readable even at a distance.
Multi-User Touch Interaction: Has 40 simultaneous touches, has the capability of supporting a dual stylus pen, and palm rejection, allowing multiple users to simultaneously write or annotate the screen without issues.
All-in-One Software Bundle: Includes the myViewBoard suite (whiteboard, ViewBoard Cast, etc.) and includes a built-in remote management system with myViewBoard Manager, allowing teachers and administrators to use it to deploy, monitor, and update content and settings remotely.
Enhanced Sound: An inbuilt soundbar along with a subwoofer delivers 40W of combined output to fill even big rooms with sound without the use of external speakers.
Flexible Connectivity & Power Delivery: has numerous HDMI ports, USB-C, 65W power delivery, USB 3.0 / USB 2.0 ports, network (LAN/WiFi), RS-232, etc., which makes it simple to connect laptops, smartphones, and media sources.
Comfort and Durability: The display is Low blue light certified, flicker-free, anti-glare tempered glass surface, and a back light of approximately 50,000 hours, which are guaranteed to be comfortable and very reliable to use over a long period.
Technical Specifications
| Feature | Specification |
|---|---|
| Model | ViewSonic IFP8650-E1 |
| Display Size (Diagonal) | 86″ |
| Native Resolution | 3840 × 2160 (4K UHD) |
| Refresh Rate | 60 Hz |
| Aspect Ratio | 16:9 |
| Brightness (Typical) | ~ 350 cd/m² |
| Static Contrast Ratio | ~ 1200:1 |
| Backlight Life | ~ 50,000 hours |
| Viewing Angles (H / V) | 178° / 178° |
| Response Time (Gray-to-Gray) | ~ 8 ms (typical) |
| Panel Surface / Glass | Anti-glare tempered glass; 7H hardness |
| Touch Technology & Points | Infrared touch; 40-point multi-touch; dual stylus tip support (3mm & 8mm) |
| Processor / OS | Quad-core (ARM Cortex-A73 + A53); Android 11 (myViewBoard OS) |
| Memory / Storage | 8 GB RAM; 64 GB internal storage |
| Audio Output | Stereo speakers + subwoofer; ~ 40 W total output |
| Connectivity Ports | 3× HDMI 2.0 in; 1× HDMI out; multiple USB 3.0 & USB 2.0; 1× USB-C (65W PD); RJ-45 LAN; RS-232; DisplayPort; WiFi module slot |
| Power Supply & Consumption | 100–240 VAC; Typical ~ 175 W; Standby < 0.5 W |
| Operation / Duty Cycle | 16 hours/day, 7 days/week |
| Physical Dimensions (W × H × D) | ~ 1988 × 1186 × 146 mm |
| Weight (Net / Gross) | ~ 84.4 kg net; ~ 112.1 kg gross (with packaging) |
| Mounting / VESA Pattern | 800 × 600 mm VESA compatible |
| Warranty | 3-year limited (parts, labour, backlight) |
Product Information
The IFP8650-E1 is intended to offer a huge and high-performance interactive space that can fit in a classroom, lecture hall, training room, or a large conference room. Its 86-inch size makes the content visible in even the rear rows, and its 4K resolution makes the text clear and fine details intact. The internal storage option of 8 GB RAM / 64 GB internal storage gives it the possibility to use apps and its internal storage to store content instead of being fully dependent on external devices.
Touch interaction has 40 simultaneous touch points; this implies that various students or participants can interact simultaneously. Dual tips (3 mm and 8 mm) and palm detection will prevent unintentional touches, enhancing the experience of writing or making scribbles. Android 11 with myViewBoard software suite, by ViewSonic, has built-in whiteboarding, casting, remote management and cloud-store integration, with minimal PC or external system requirements.
Regarding hardware construction, the panel uses anti-glare tempered glass that is durable and will produce a better view even in intense lighting. Angles of viewing are wide (178/178), thus ensuring that side or off-centre viewers can still view good colour and contrast. Response time and brightness are sufficient in a normal education or presentation environment. Still, in high-ambient-light conditions in areas where direct sunlight is visible, their visibility will be reduced.
Energy usage is average (around 175 W or so) because the device is huge and bulky (about 84 kg), and it is necessary to secure it with structural and wall mounting. Large wall mounts can fit in the VESA pattern (800x600 mm). The warranty of 3 years for the backlight, parts, and labor provides confidence in long-term use.
